Yamaichi, IC26V 2.54 mm Pitch Straight 28 Way, Surface Turned Pin DIL Socket, 1A

View all DIL Sockets
Bulk discount available

Subtotal (1 unit)*

MYR26.48

Add to Basket
Select or type quantity
In Stock
  • Plus 2 unit(s) shipping from 02 February 2026
  • Plus 4 unit(s) shipping from 16 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per Unit
1 - 4MYR26.48
5 - 14MYR25.16
15 - 49MYR23.90
50 - 99MYR22.72
100 +MYR21.63

*price indicative

RS Stock No.:
240-5934
Mfr. Part No.:
IC26V-2803-GG4
Manufacturer:
Yamaichi
Find similar products by selecting one or more attributes.
Select all

Brand

Yamaichi

Product Type

DIL Socket

Number of Contacts

28

Mount Type

Surface

Pin Type

Turned

Current

1A

Pitch

2.54mm

Row Width

7.62mm

Voltage

700 V

Contact Plating

Gold

Orientation

Straight

Termination Type

Solder

Minimum Operating Temperature

-65°C

Maximum Operating Temperature

125°C

Standards/Approvals

No

Depth

3.9mm

Width

10.13 mm

Length

35.53mm

Series

IC26V

Contact Material

Copper Alloy

COO (Country of Origin):
PH
The Yamaichi IC26V Series DIP is highly reliable four point contact design. It has machined sleeves eliminating solder or flux penetration. It stand-off preventing blowholes in solder joints. The plating of inner contact and of solder terminal are of gold. They have a operating temperature of -65 to +125 degree Celsius and current Rating of 1A.

RoHS compliant

No. of contact - 28

Insulation Resistance - 1000M ohm

Withstanding voltage - 700VAC rms/minute

Contact Resistance - 20M ohm max
