MEAN WELL DC-DC Converter, 24V dc/ 1.1A Output, 9.2 → 18 V dc Input, 25W, Chassis Mount, +60°C Max Temp -10°C

RS Stock No.:: 678-3556
Mfr. Part No.:: SD-25A-24
Manufacturer:: MEAN WELL

MEAN WELL DC-DC Converter, 24V dc/ 1.1A Output, 9.2 → 18 V dc Input, 25W, Chassis Mount, +60°C Max Temp -10°C

6 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ

24 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ

Added

Price Each

MYR145.71

Units	Per Unit
1 - 4	MYR145.71
5 - 9	MYR142.64
10 - 24	MYR138.36
25 - 49	MYR134.97
50 +	MYR132.02

RS Stock No.:: 678-3556
Mfr. Part No.:: SD-25A-24
Manufacturer:: MEAN WELL

Technical data sheets

Legislation and Compliance

COO (Country of Origin):: CN

Product Details

SD-25 Series Single Output Enclosed Regulated Isolated DC-DC Converter

High reliability
Wide 2:1 input voltage range
Regulated outputs
Easy installation - screw terminals
Adjustable output voltage
EMC meets EN 55022 Class B
LED power-on indicator
Short circuit, overload and overvoltage protection
1.5kV input / output isolation

Note

De-rating below 0 and above 40°C.
MTBF to MIL-HDBK-217F (25°C).

Specifications

Attribute	Value
Output Voltage	24V dc
Input Voltage Range	9.2 → 18 V dc
Power Rating	25W
Input Voltage Nominal	12 V dc
Output Current	1.1A
Mounting Type	Chassis Mount
Isolated	Yes
Number of Outputs	1
Output Voltage Adjustment Range	23 → 30V
Isolation Voltage	1.5kV ac
Length	99mm
Depth	36mm
Width	97mm
Load Regulation	±0.2%
Maximum Temperature	+60°C
Efficiency	75%
Standards Met	3, 4, 5, 6, 8, EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A
Minimum Temperature	-10°C
