Select all	Attribute	Value
	Brand	TRACOPOWER
	Output Voltage	54V dc
	Input Voltage Range	36-160 V dc
	Power Rating	40W
	Input Voltage Nominal	110 V dc
	Output Current	741mA
	Mounting Type	PCB
	Isolated	Yes
	Number of Outputs	1
	Output Voltage Adjustment Range	–15 → +5%
	Package	2 x 1 in
	Isolation Voltage	3'000V dc
	Depth	50.8mm
	Length	25.4mm
	Width	11mm
	Series	THR 40WI
	Railway Approved	No
	Load Regulation	0.5%
	Medical Approved	No
	Minimum Temperature	-40°C
	Standards Met	IEC/EN 62368-1
	Maximum Temperature	+80°C
	Efficiency	90%

	Select all
	Brand TRACOPOWER
	Output Voltage 54V dc
	Input Voltage Range 36-160 V dc
	Power Rating 40W
	Input Voltage Nominal 110 V dc
	Output Current 741mA
	Mounting Type PCB
	Isolated Yes
	Number of Outputs 1
	Output Voltage Adjustment Range –15 → +5%
	Package 2 x 1 in
	Isolation Voltage 3'000V dc
	Depth 50.8mm
	Length 25.4mm
	Width 11mm
	Series THR 40WI
	Railway Approved No
	Load Regulation 0.5%
	Medical Approved No
	Minimum Temperature -40°C
	Standards Met IEC/EN 62368-1
	Maximum Temperature +80°C
	Efficiency 90%

TRACOPOWER THR 40WI Isolated DC-DC Converter, 54V dc/ 741mA Output, 36-160 V dc Input, 40W, PCB, +80°C Max Temp -40°C

FREE delivery for orders over MYR500.00

TRACOPOWER THR 40WI Series Isolated DC-DC Converter, 36 → 160 V DC Input, PCB Mount - THR 40-72154WI

Features & Benefits

Applications

Can it handle a wide range of input voltages?

Will it provide protection against overloading?

Is it suitable for transportation applications?

Can it be easily mounted on a PCB?

Is it efficient in maintaining regulated output voltages?
