Mascot 2.5 x 5.5 x 12 mm Female Coaxial Plug with Snap Lock, 2.1 x 5.5 x 12 mm Female Coaxial Plug with Snap Lock
- RS Stock No.:
- 452-8489
- Mfr. Part No.:
- 2124000041
- Manufacturer:
- Mascot
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
MYR255.70
FREE delivery for orders over RM 150.00
In Stock
- Plus 31 unit(s) shipping from 23 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 - 9 | MYR255.70 |
| 10 - 49 | MYR251.21 |
| 50 + | MYR244.67 |
*price indicative
- RS Stock No.:
- 452-8489
- Mfr. Part No.:
- 2124000041
- Manufacturer:
- Mascot
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Mascot | |
| Product Type | AC/DC Adapter | |
| Sub Type | Switched Mode Power Supply | |
| Plug Type | 2-Pin (IEC) | |
| Output Voltage | 6V dc | |
| Power | 9W | |
| Output Connector Type | 2.5 x 5.5 x 12 mm Female Coaxial Plug with Snap Lock, 2.1 x 5.5 x 12 mm Female Coaxial Plug with Snap Lock | |
| Cable Length | 1.8m | |
| Number of Outputs | 1 | |
| Minimum Operating Temperature | -20°C | |
| Adapter Current | 1.5A | |
| Input Connector Type | IEC 320 | |
| Maximum Operating Temperature | 40°C | |
| Depth | 32mm | |
| Width | 45mm | |
| Standards/Approvals | EN 60601-1-2 | |
| Length | 90mm | |
| Efficiency | 83% | |
| Maximum Input Voltage | 230V ac | |
| Series | 2124 | |
| Minimum Input Voltage | 90V ac | |
| Load Regulation | ±1 % | |
| Select all | ||
|---|---|---|
Brand Mascot | ||
Product Type AC/DC Adapter | ||
Sub Type Switched Mode Power Supply | ||
Plug Type 2-Pin (IEC) | ||
Output Voltage 6V dc | ||
Power 9W | ||
Output Connector Type 2.5 x 5.5 x 12 mm Female Coaxial Plug with Snap Lock, 2.1 x 5.5 x 12 mm Female Coaxial Plug with Snap Lock | ||
Cable Length 1.8m | ||
Number of Outputs 1 | ||
Minimum Operating Temperature -20°C | ||
Adapter Current 1.5A | ||
Input Connector Type IEC 320 | ||
Maximum Operating Temperature 40°C | ||
Depth 32mm | ||
Width 45mm | ||
Standards/Approvals EN 60601-1-2 | ||
Length 90mm | ||
Efficiency 83% | ||
Maximum Input Voltage 230V ac | ||
Series 2124 | ||
Minimum Input Voltage 90V ac | ||
Load Regulation ±1 % | ||
- COO (Country of Origin):
- NO
Mascot 9W to 60W Medical Approved Single Output Switch Mode Desktop Power Supply
Medically approved (EN 60601) external switch mode power supplies
High efficiency
Fully regulated output
Over voltage and short circuit protection
Isolation 4kV input/output
EMC immunity to EN 50082-1, medical EN 60601-1-2
1.8m (approx.) output lead with polarity inverter
2-pin or 3-pin IEC320 input connection
Note
Non Compliant For Industrial Use Only, not in scope of Regulation (EC) No 125/2009.
Approvals
UL recognised component for Canada and US (12 & 24V only)
Standards
EN 60950 EN 60601 (UL 2601-1)
Supplied with
2 loose connectors with snap-lock feature, allowing 4 connection options, 2.1x5.5x12mm and 2.5x5.5x12mm female co-ax plugs.
