Wurth, WE-PD4 Unshielded Wire-wound SMD Inductor with a Ferrite Core, 22 μH ±15% Unshielded 4A Idc
- RS Stock No.:
- 163-3280
- Mfr. Part No.:
- 74457122
- Manufacturer:
- Wurth Elektronik
Bulk discount available
Subtotal (1 reel of 250 units)**
MYR2,135.25
Temporarily out of stock - back order for despatch 05/12/2025, delivery within 4 working days from despatch date*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over MYR500.00
Units | Per Unit | Per Reel** |
---|---|---|
250 - 250 | MYR8.541 | MYR2,135.25 |
500 - 750 | MYR8.353 | MYR2,088.25 |
1000 + | MYR8.199 | MYR2,049.75 |
**price indicative
- RS Stock No.:
- 163-3280
- Mfr. Part No.:
- 74457122
- Manufacturer:
- Wurth Elektronik
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Wurth Elektronik | |
Inductance | 22 μH | |
Maximum DC Current | 4A | |
Length | 22mm | |
Depth | 15mm | |
Height | 7mm | |
Dimensions | 22 x 15 x 7mm | |
Shielded | No | |
Tolerance | ±15% | |
Maximum DC Resistance | 47mΩ | |
Series | WE-PD4 | |
Core Material | Ferrite | |
Maximum Self Resonant Frequency | 14MHz | |
Minimum Operating Temperature | -40°C | |
Inductor Construction | Unshielded | |
Maximum Operating Temperature | +125°C | |
Select all | ||
---|---|---|
Brand Wurth Elektronik | ||
Inductance 22 μH | ||
Maximum DC Current 4A | ||
Length 22mm | ||
Depth 15mm | ||
Height 7mm | ||
Dimensions 22 x 15 x 7mm | ||
Shielded No | ||
Tolerance ±15% | ||
Maximum DC Resistance 47mΩ | ||
Series WE-PD4 | ||
Core Material Ferrite | ||
Maximum Self Resonant Frequency 14MHz | ||
Minimum Operating Temperature -40°C | ||
Inductor Construction Unshielded | ||
Maximum Operating Temperature +125°C | ||
