Phoenix Contact Straight Male 3 way M8 to Straight Female 3 way M8 Sensor Actuator Cable, 3m

RS Stock No.:: 856-6012
Mfr. Part No.:: 1458693
Manufacturer:: Phoenix Contact

Phoenix Contact Straight Male 3 way M8 to Straight Female 3 way M8 Sensor Actuator Cable, 3m

Price Each

MYR248.40

Temporarily out of stock - back order for despatch 17/01/2025, delivery within 4 working days from despatch date*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over MYR700.00

Units	Per Unit
1 +	MYR248.40

RS Stock No.:: 856-6012
Mfr. Part No.:: 1458693
Manufacturer:: Phoenix Contact

Datasheet

Attribute	Value
Series	SAC-3P-Y/2X
Number of Cores	3
Cross Sectional Area	0.25 mm²
Sheath Colour	Black/Grey
Length	3m
Sheath Material	PUR
Connector 1 Gender	Male
Connector 1	M8
Connector 1 Orientation	Straight
Connector 1 Number of Contacts	3
Connector 2 Orientation	Straight
Connector 2 Number of Contacts	3
Connector 2	M8
Connector 2 Gender	Female
Connector 2 Housing Gender	Female
Current Rating	4 A
Voltage Rating	30 V
IP Rating	IP65, IP67, IP68
Oil Resistant	Yes
Cable Shape	Twisted Pair
Insulation Material	PP
American Wire Gauge	22 AWG
Outer Diameter	4.4mm
Connector 1 Housing Gender	Male
Minimum Bend Radius	22 mm (Fixed), 44 mm (Movable)
Conductor Material	Bare Cu litz wires
