Murrelektronik Limited Straight Female 4 way M12 to Unterminated Sensor Actuator Cable, 5m
- RS Stock No.:
- 196-0684
- Mfr. Part No.:
- 7000-12021-6340500
- Manufacturer:
- Murrelektronik Limited
Subtotal (1 unit)**
MYR140.59
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over MYR500.00
Units | Per Unit |
|---|---|
| 1 - 4 | MYR140.59 |
| 5 - 9 | MYR137.63 |
| 10 - 24 | MYR133.50 |
| 25 + | MYR129.48 |
**price indicative
- RS Stock No.:
- 196-0684
- Mfr. Part No.:
- 7000-12021-6340500
- Manufacturer:
- Murrelektronik Limited
Select all | Attribute | Value |
|---|---|---|
| Brand | Murrelektronik Limited | |
| Series | A-Coded | |
| Number of Cores | 4 | |
| Cross Sectional Area | 0.34 mm² | |
| Sheath Material | PUR | |
| Sheath Colour | Black | |
| Length | 5m | |
| Connector 1 Number of Contacts | 4 | |
| Connector 1 | M12 | |
| Connector 1 Gender | Female | |
| Connector 1 Orientation | Straight | |
| Connector 2 | Unterminated | |
| Current Rating | 4 A | |
| Voltage Rating | 30 V ac/dc, 250 V ac/dc | |
| IP Rating | IP65, IP66K, IP67 | |
| Size of Strands | 0.1 mm | |
| Connector 1 Housing Gender | Male | |
| Cable Shape | Single Core | |
| Outer Diameter | 4.5mm | |
| Conductor Resistance | 57 O/km | |
| American Wire Gauge | 22 AWG | |
| Oil Resistant | Yes | |
| Maximum Operating Temperature | +80 (Fixed, +85 °C, Mobile) °C | |
| Fire Behaviour | Flame Retardant | |
| Core Strands | 42 x 0.1 mm | |
| Operating Temperature Range | -25 → +80 (Mobile) °C, -25 → +85 °C, -40 → +80 (Fixed) °C | |
| Minimum Bend Radius | 22.5 (Fixed) mm, 45 (Moving) mm | |
| Minimum Operating Temperature | -25 (Mobile) °C, -40 (Fixed) °C | |
| Number of Strands | 42 | |
Select all | ||
|---|---|---|
Brand Murrelektronik Limited | ||
Series A-Coded | ||
Number of Cores 4 | ||
Cross Sectional Area 0.34 mm² | ||
Sheath Material PUR | ||
Sheath Colour Black | ||
Length 5m | ||
Connector 1 Number of Contacts 4 | ||
Connector 1 M12 | ||
Connector 1 Gender Female | ||
Connector 1 Orientation Straight | ||
Connector 2 Unterminated | ||
Current Rating 4 A | ||
Voltage Rating 30 V ac/dc, 250 V ac/dc | ||
IP Rating IP65, IP66K, IP67 | ||
Size of Strands 0.1 mm | ||
Connector 1 Housing Gender Male | ||
Cable Shape Single Core | ||
Outer Diameter 4.5mm | ||
Conductor Resistance 57 O/km | ||
American Wire Gauge 22 AWG | ||
Oil Resistant Yes | ||
Maximum Operating Temperature +80 (Fixed, +85 °C, Mobile) °C | ||
Fire Behaviour Flame Retardant | ||
Core Strands 42 x 0.1 mm | ||
Operating Temperature Range -25 → +80 (Mobile) °C, -25 → +85 °C, -40 → +80 (Fixed) °C | ||
Minimum Bend Radius 22.5 (Fixed) mm, 45 (Moving) mm | ||
Minimum Operating Temperature -25 (Mobile) °C, -40 (Fixed) °C | ||
Number of Strands 42 | ||
