Honeywell Roller Lever Micro Switch, PCB Terminal Terminal, 3A, 125 V ac, 60 V, SPDT, IP40

RS Stock No.:: 205-6086
Mfr. Part No.:: ZX40E20F01
Manufacturer:: Honeywell

Honeywell Roller Lever Micro Switch, PCB Terminal Terminal, 3A, 125 V ac, 60 V, SPDT, IP40

Subtotal (1 box of 1000 units)*

MYR13,473.00

FREE delivery for orders over RM 500.00

Temporarily out of stock

Shipping from 05 August 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per Unit	Per Box*
1000 +	MYR13.473	MYR13,473.00

*price indicative

RS Stock No.:: 205-6086
Mfr. Part No.:: ZX40E20F01
Manufacturer:: Honeywell

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Honeywell
	Actuator Type	Roller Lever
	Product Type	Micro Switch
	Terminal Type	PCB Terminal
	Contact Configuration	SPDT
	Housing Material	Polyamide
	IP Rating	IP40
	Operating Force	150g
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	85°C
	Contact AC Voltage	125V ac
	Microswitch Type	Subminiature
	Contact DC Voltage	60V
	Depth	6.5mm
	Hazardous Area Certification	UL, RoHS, ENEC, cUL, CQC
	Mechanical Life	3000000min
	Length	12.8mm
	Width	5.8mm
	Standards/Approvals	UL, RoHS, ENEC, cUL, CQC
	Series	ZX

	Select all
	Brand Honeywell
	Actuator Type Roller Lever
	Product Type Micro Switch
	Terminal Type PCB Terminal
	Contact Configuration SPDT
	Housing Material Polyamide
	IP Rating IP40
	Operating Force 150g
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 85°C
	Contact AC Voltage 125V ac
	Microswitch Type Subminiature
	Contact DC Voltage 60V
	Depth 6.5mm
	Hazardous Area Certification UL, RoHS, ENEC, cUL, CQC
	Mechanical Life 3000000min
	Length 12.8mm
	Width 5.8mm
	Standards/Approvals UL, RoHS, ENEC, cUL, CQC
	Series ZX

COO (Country of Origin):: CN

Honeywell Series ZX Micro Switch, 3A Switch Contact Current, 125V Contact AC Voltage - ZX40E20F01

This micro switch is a Compact electromechanical device designed to detect mechanical movement and provide reliable switching in control and sensing assemblies. It is tailored for PCB mounting and features a roller lever actuator to convert linear or rotational motion into electrical switching, suitable for integration into automated and electronic systems.

Features and Benefits:

• Rated for 125V AC and 60V DC carrying up to 3A providing robust signal switching
• Roller lever actuator with 150g operating force enabling precise actuation
• Subminiature construction offering space‑efficient PCB installation
• Polyamide housing with IP40 protection ensuring Basic ingress defence
• Mechanical endurance of 3 million cycles delivering extended operational life
• Operates between −40°C and 85°C allowing use across varied temperature ranges

Applications

• Suitable for position sensing in conveyor automation systems
• Ideal for limit detection in electromechanical actuators
• Used with control boards in consumer appliance assemblies
• Can be used for user‑input detection on industrial control panels
• Used for safety interlocks on Compact machinery modules

What Terminal format does it use for circuit connection?

It uses PCB terminals designed for direct soldering to printed circuit boards for secure electrical and mechanical mounting.

Which approvals indicate suitability for international projects?

It holds multiple approvals from recognised bodies including UL, ENEC, cUL, RoHS and CQC which demonstrate adherence to several international standards.

How does the switch’s actuator type affect installation options?

The roller lever actuator permits actuation by shafts or cams with a rolling contact, reducing wear on the actuation surface and allowing flexible alignment in confined assemblies.

What material considerations affect chemical or thermal exposure?

The enclosure is MADE from polyamide, which offers a balance of mechanical stability and resistance to moderate thermal and environmental stresses.

What switching configuration does it provide for circuit design?

It is arranged as a single‑pole changeover contact enabling one common contact to alternate between two circuits during operation.
