Units	Per Unit	Per Pack**
5 - 45	MYR7.906	MYR39.53
50 - 95	MYR7.666	MYR38.33
100 +	MYR7.438	MYR37.19

Select all	Attribute	Value
	Brand	Texas Instruments
	Logic Function	NAND
	Mounting Type	Through Hole
	Number of Elements	4
	Number of Inputs per Gate	2
	Schmitt Trigger Input	No
	Package Type	PDIP
	Pin Count	14
	Logic Family	LS
	Maximum Operating Supply Voltage	5.25 V
	Maximum High Level Output Current	-0.25mA
	Maximum Propagation Delay Time @ Maximum CL	32 ns @ 5 V
	Minimum Operating Supply Voltage	4.75 V
	Maximum Low Level Output Current	24mA
	Length	19.3mm
	Height	4.57mm
	Minimum Operating Temperature	0 °C
	Dimensions	19.3 x 6.35 x 4.57mm
	Propagation Delay Test Condition	45pF
	Width	6.35mm
	Maximum Operating Temperature	+70 °C
	Output Type	Open Collector

	Select all
	Brand Texas Instruments
	Logic Function NAND
	Mounting Type Through Hole
	Number of Elements 4
	Number of Inputs per Gate 2
	Schmitt Trigger Input No
	Package Type PDIP
	Pin Count 14
	Logic Family LS
	Maximum Operating Supply Voltage 5.25 V
	Maximum High Level Output Current -0.25mA
	Maximum Propagation Delay Time @ Maximum CL 32 ns @ 5 V
	Minimum Operating Supply Voltage 4.75 V
	Maximum Low Level Output Current 24mA
	Length 19.3mm
	Height 4.57mm
	Minimum Operating Temperature 0 °C
	Dimensions 19.3 x 6.35 x 4.57mm
	Propagation Delay Test Condition 45pF
	Width 6.35mm
	Maximum Operating Temperature +70 °C
	Output Type Open Collector

Texas Instruments SN74LS38N, Quad 2-Input NAND Logic Gate, 14-Pin PDIP

FREE delivery for orders over MYR500.00

74LS Family Logic Gates, Texas Instruments

For these non-cancellable (NC), and non-returnable (NR) products, Terms and Conditions apply.
