Omron D4n Series Roller Plunger Limit Switch, 1 NO/1 NC, IP67, Metal Housing, 240V

RS Stock No.:: 215-5035
Mfr. Part No.:: D4N-4232
Manufacturer:: Omron

Omron D4n Series Roller Plunger Limit Switch, 1 NO/1 NC, IP67, Metal Housing, 240V

Subtotal (1 unit)*

MYR123.37

FREE delivery for orders over RM 500.00

In Stock

38 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per Unit
1 +	MYR123.37

*price indicative

RS Stock No.:: 215-5035
Mfr. Part No.:: D4N-4232
Manufacturer:: Omron

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Omron
	Actuator Type	Roller Plunger
	Product Type	Limit Switch
	IP Rating	IP67
	Contact Configuration	1 NO/1 NC
	Housing Material	Metal
	Contact Type	Snap Action
	Terminal Type	Screw
	Series	D4n
	Minimum Operating Temperature	-10°C
	Switching AC Voltage	240V
	Maximum Operating Temperature	80°C
	Depth	30mm
	Standards/Approvals	CCC, CE, CSA, RoHS, UL
	Width	50mm
	Length	72mm
	Hazardous Area Certification	NO
	Mounting Orientation	Multi Directional
	Conduit Entry	M20
	Operating Force	6.4N
	Mechanical Life	10000000Cycles

	Select all
	Brand Omron
	Actuator Type Roller Plunger
	Product Type Limit Switch
	IP Rating IP67
	Contact Configuration 1 NO/1 NC
	Housing Material Metal
	Contact Type Snap Action
	Terminal Type Screw
	Series D4n
	Minimum Operating Temperature -10°C
	Switching AC Voltage 240V
	Maximum Operating Temperature 80°C
	Depth 30mm
	Standards/Approvals CCC, CE, CSA, RoHS, UL
	Width 50mm
	Length 72mm
	Hazardous Area Certification NO
	Mounting Orientation Multi Directional
	Conduit Entry M20
	Operating Force 6.4N
	Mechanical Life 10000000Cycles

Omron D4n Series Limit Switch, IP67, 10A Switching Current - D4N-4232

This limit switch is a Compact electromechanical device for position detection and circuit switching in industrial automation. It employs a roller plunger actuator and a plastic enclosure engineered for dust and water resistance, allowing use in controlled indoor machinery environments. Terminals accept screw connections and the unit is configured for single-conduit M20 cable entry, suited to panel and field installations where a Compact, multi-orientable actuator is required.

Features & Benefits

• IP67-rated enclosure for protected indoor water immersion
• 1NO/1NC snap-action contacts for quick switching response
• Rated for 10A at 240VAC and 250VDC to handle standard loads
• Mechanical life of 15,000,000 operations for extended service
• Operating force 6.4N reduces actuator drive torque requirements
• Multi-directional head mounting for flexible installation positions

Applications

• Suitable for machine-tool end-of-travel detection
• Ideal for conveyor indexing and product counting systems
• used with lift and hoist limit sensing mechanisms
• Can be used for safety interlocks in industrial enclosures
• Suitable for automated packaging machine position feedback

What Terminal type is provided for wiring connections?

The unit uses screw Terminals designed for secure conductor attachment with recommended torque for Terminal screws specified to prevent loosening.

How does the actuator type influence installation?

The roller plunger actuator gives a positive mechanical input Interface and tolerates linear contact from moving parts while offering predictable operating angles and travel characteristics.

What environmental limits affect operation?

The device is intended for indoor use and its rated ambient operating range spans from −30°C to +70°C without icing

it is not advised for locations with hazardous gases or continuous oil immersion.

Can it be mounted in different orientations?

Yes, the head and actuator design allow multiple mounting orientations to match system geometry and actuator approach directions.
