Diodes Inc BC847AT-7-F NPN Transistor, 100 mA, 45 V, 3-Pin SOT-523
- RS Stock No.:
- 711-4872
- Mfr. Part No.:
- BC847AT-7-F
- Manufacturer:
- DiodesZetex
1650 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Price Each (In a Pack of 50)
MYR0.873
Units | Per Unit | Per Pack* |
|---|---|---|
| 50 - 700 | MYR0.873 | MYR43.65 |
| 750 - 1450 | MYR0.808 | MYR40.40 |
| 1500 + | MYR0.748 | MYR37.40 |
*price indicative
- RS Stock No.:
- 711-4872
- Mfr. Part No.:
- BC847AT-7-F
- Manufacturer:
- DiodesZetex
Technical data sheets
Legislation and Compliance
Product Details
Small Signal NPN Transistors, Diodes Inc
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Transistors, Diodes Inc
Specifications
Attribute | Value |
|---|---|
| Transistor Type | NPN |
| Maximum DC Collector Current | 100 mA |
| Maximum Collector Emitter Voltage | 45 V |
| Package Type | SOT-523 (SC-89) |
| Mounting Type | Surface Mount |
| Maximum Power Dissipation | 150 mW |
| Minimum DC Current Gain | 110 |
| Transistor Configuration | Single |
| Maximum Collector Base Voltage | 50 V |
| Maximum Emitter Base Voltage | 6 V |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Maximum Operating Temperature | +150 °C |
| Dimensions | 1.7 x 0.85 x 0.8mm |
| Minimum Operating Temperature | -55 °C |
