Digi International XB2B-WFWT-001 3.46 V WiFi Module, 802.11 b/g/n

This image is representative of the product range

View all Wi-Fi Modules

Subtotal (1 unit)*

MYR298.41

Add to Basket
Select or type quantity
In Stock
  • 9 unit(s) ready to ship from another location
  • Plus 59 unit(s) shipping from 10 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per Unit
1 +MYR298.41

*price indicative

RS Stock No.:
818-7338
Mfr. Part No.:
XB2B-WFWT-001
Manufacturer:
Digi International
Find similar products by selecting one or more attributes.
Select all

Brand

Digi International

Product Type

WiFi Module

Supported Security Standards

WPA-PSK, WPA2-PSK, WEP

Data Rate

72Mbps

Frequency

2.4GHz

Length

24.38mm

Interface Type

SPI, UART

Minimum Supply Voltage

3.14V

Maximum Supply Voltage

3.46V

Width

32.94 mm

Transmitting Supply Current

309mA

Receiving Supply Current

100mA

Minimum Operating Temperature

-30°C

Supported Protocols

802.11 b/g/n

Maximum Operating Temperature

85°C

Series

XB2B-WFWT-001

Standards/Approvals

No

COO (Country of Origin):
TH

XBee Embedded Wi-Fi Module


XBee Embedded Wi-Fi transceiver modules are IEEE 802.11b/g/n compliant, providing wireless connectivity to an project via serial UART/SPI interfaces. Using SoftAP Provisioning mode, any Smartphone or Tablet with a web browser can connect to the XBee Wi-Fi and configure the module to connect to an existing Wi-Fi network. The XBee Wi-Fi module shares a common footprint with other XBee modules.This allows different XBee technologies to be drop-in replacements for each other; developers can switch from IEEE 802.11 standard to IEEE 802.15.4 for example.

Carrier Frequency: 2.4GHz ISM Band with 13 channels

RF Output Power: up to +16dBm (+13dBm for Europe/Australia/Brazil)

Receiver Sensitivity: -97 to -71dBm

OTA Data Rates: 11Mbps (802.11b), 54Mbps (802.11g), 72Mbps (802.11n)

Host communication: serial UART/SPI

Security: WEP, WPA-PSK and WPA2-PSK

4 channel 12-bit ADC

10 x GPIO pins

Power supply: +3.14V to +3.46Vdc

Operating temperature range: -30 to +85°C

Dimensions: 24.4 x 32.9 x 7mm (DIL), 22 x 34 x 3mm (SMT)

Applications: Wireless sensor networks, communication for the Internet of Things (IoT)

RS Product Codes

818-7329 XB2B-WFPS-001 SMT, PCB Antenna

818-7326 XB2B-WFUS-001 SMT, U.FL Antenna Connector

818-7322 XB2B-WFPT-001 DIL, PCB Antenna

818-7335 XB2B-WFUT-001 DIL, U.FL Antenna Connector

818-7338 XB2B-WFWT-001 DIL, Whip Antenna

818-7332 XB2B-WFST-001 DIL, RPSMA Antenna Connector

Approvals

FCC, IC, ETSI, C-TICK, Telec, Anatel
