Units	Per Unit
1 - 24	MYR39.05
25 +	MYR37.87

Select all	Attribute	Value
	Brand	TE Connectivity
	Contact Configuration	Single Pole Double Throw (SPDT)
	Switch Operation	On-(On)
	Contact Current Rating	4 A @ 30 V dc
	Mounting Type	Panel Mount
	Terminal Type	Solder
	Panel Cut Out Diameter	6.2mm
	Actuator Length	10.5mm
	Actuator Material	Chrome Plated Brass
	Voltage Rating	125 V ac, 250V ac
	Contact Resistance	0.01Ω
	Contact Material	Fine Silver
	Minimum Operating Temperature	-20°C
	Operating Temperature Range	-20 → +80°C
	Standards Met	CSA Recognised, RoHS, UL 94V-0
	Maximum Operating Temperature	+80°C
	Mechanical Life	100000Operations

	Select all
	Brand TE Connectivity
	Contact Configuration Single Pole Double Throw (SPDT)
	Switch Operation On-(On)
	Contact Current Rating 4 A @ 30 V dc
	Mounting Type Panel Mount
	Terminal Type Solder
	Panel Cut Out Diameter 6.2mm
	Actuator Length 10.5mm
	Actuator Material Chrome Plated Brass
	Voltage Rating 125 V ac, 250V ac
	Contact Resistance 0.01Ω
	Contact Material Fine Silver
	Minimum Operating Temperature -20°C
	Operating Temperature Range -20 → +80°C
	Standards Met CSA Recognised, RoHS, UL 94V-0
	Maximum Operating Temperature +80°C
	Mechanical Life 100000Operations

TE Connectivity Toggle Switch, Panel Mount, On-(On), SPDT, Solder Terminal, 125V ac
