i-Autoc Solid State Relay, 16 A Load, Panel Mount, 440 V ac Load, 32 V dc Control
- RS Stock No.:
- 102-5545
- Mfr. Part No.:
- KSIM380D16-L
- Manufacturer:
- i-Autoc
Subtotal (1 unit)**
MYR86.80
126 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over MYR500.00
Real time qty checker
Units | Per Unit |
---|---|
1 + | MYR86.80 |
**price indicative
- RS Stock No.:
- 102-5545
- Mfr. Part No.:
- KSIM380D16-L
- Manufacturer:
- i-Autoc
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | i-Autoc | |
Maximum Load Current | 16 A | |
Mounting Type | Panel Mount | |
Maximum Load Voltage | 440 V ac | |
Minimum Load Voltage | 48 V ac | |
Maximum Control Voltage | 32 V dc | |
Minimum Control Voltage | 4 V dc | |
Switching Type | Zero Cross | |
Control Voltage Range | 4 → 32 V dc | |
Terminal Type | Screw | |
Output Device | Triac | |
Relay Type | Single Phase | |
Load Voltage Range | 48 → 440V ac | |
Maximum Turn On Time | 1 (+1/2 cycle) ms | |
Dimensions | 38.2 x 28.1 x 19mm | |
Height | 19mm | |
Depth | 28.1mm | |
Standards Met | CE | |
Special Features | Internal RC Protection Circuit, LED Indication | |
Off State Leakage Current | 5 mA | |
Length | 38.2mm | |
Operating Temperature Range | -30 → +80°C | |
Select all | ||
---|---|---|
Brand i-Autoc | ||
Maximum Load Current 16 A | ||
Mounting Type Panel Mount | ||
Maximum Load Voltage 440 V ac | ||
Minimum Load Voltage 48 V ac | ||
Maximum Control Voltage 32 V dc | ||
Minimum Control Voltage 4 V dc | ||
Switching Type Zero Cross | ||
Control Voltage Range 4 → 32 V dc | ||
Terminal Type Screw | ||
Output Device Triac | ||
Relay Type Single Phase | ||
Load Voltage Range 48 → 440V ac | ||
Maximum Turn On Time 1 (+1/2 cycle) ms | ||
Dimensions 38.2 x 28.1 x 19mm | ||
Height 19mm | ||
Depth 28.1mm | ||
Standards Met CE | ||
Special Features Internal RC Protection Circuit, LED Indication | ||
Off State Leakage Current 5 mA | ||
Length 38.2mm | ||
Operating Temperature Range -30 → +80°C | ||
