PTR HARTMANN AK1550 Series Pluggable Terminal Block, 5-Contact, 3.5 mm Pitch, 1 Row, AK1550/05-3.5
- RS Stock No.:
- 283-8013
- Distrelec Article No.:
- 148-41-203
- Mfr. Part No.:
- AK1550/05-3.5
- Manufacturer:
- PTR HARTMANN
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
MYR5.67
- RS Stock No.:
- 283-8013
- Distrelec Article No.:
- 148-41-203
- Mfr. Part No.:
- AK1550/05-3.5
- Manufacturer:
- PTR HARTMANN
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | PTR HARTMANN | |
| Number of Contacts | 5 | |
| Product Type | Pluggable Terminal Block | |
| Pitch | 3.5mm | |
| Current | 8A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.14mm² | |
| Housing Material | Polyamide | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 16AWG | |
| Orientation | Straight | |
| Colour | Green | |
| Voltage | 300V | |
| Series | AK1550 | |
| Standards/Approvals | VDE | |
| Width | 17.5mm | |
| Select all | ||
|---|---|---|
Brand PTR HARTMANN | ||
Number of Contacts 5 | ||
Product Type Pluggable Terminal Block | ||
Pitch 3.5mm | ||
Current 8A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.14mm² | ||
Housing Material Polyamide | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 16AWG | ||
Orientation Straight | ||
Colour Green | ||
Voltage 300V | ||
Series AK1550 | ||
Standards/Approvals VDE | ||
Width 17.5mm | ||
- COO (Country of Origin):
- DE
The Female header is a versatile component designed for various electronic applications. With its solid core wire size of minimum 0.14mm and maximum 1.5mm, this product offers reliable connectivity and flexibility. The operating temperature ranging from -30°C to 105°C ensures optimal performance in different environments.
Solid core wire size suitable for a wide range of applications
Operating temperature range of -30°C to 105°C for versatility
Flammability class UL 94 V-0 for safety compliance
Peak soldering time recommendations for efficient soldering process
Rated voltage of 300V and rated current of 8A for reliable power distribution
