Myrra 3.3V dc 1 Output PCB Mount PCB Transformer, 1 → 2.75W
- RS Stock No.:
- 183-8313
- Mfr. Part No.:
- 48021
- Manufacturer:
- Myrra
Bulk discount available
Subtotal (1 unit)*
MYR31.93
FREE delivery for orders over RM 500.00
In Stock
- 83 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 - 4 | MYR31.93 |
| 5 - 9 | MYR31.26 |
| 10 - 19 | MYR30.33 |
| 20 - 49 | MYR29.57 |
| 50 + | MYR28.91 |
*price indicative
- RS Stock No.:
- 183-8313
- Mfr. Part No.:
- 48021
- Manufacturer:
- Myrra
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Myrra | |
| Secondary Voltage Rating | 3.3V dc | |
| Power Rating | 1 → 2.75W | |
| Primary Voltage Rating | 100 → 240 V ac, 140 → 340 V dc | |
| Number of Outputs | 1 | |
| Length | 25mm | |
| Width | 25mm | |
| Depth | 16mm | |
| Dimensions | 25 x 25 x 16mm | |
| Weight | 16g | |
| Mounting Type | PCB Mount | |
| Minimum Temperature | -25°C | |
| Efficiency | 63% | |
| Maximum Temperature | +80°C | |
| Minimum Operating Frequency | 47Hz | |
| Maximum Operating Frequency | 63Hz | |
| Select all | ||
|---|---|---|
Brand Myrra | ||
Secondary Voltage Rating 3.3V dc | ||
Power Rating 1 → 2.75W | ||
Primary Voltage Rating 100 → 240 V ac, 140 → 340 V dc | ||
Number of Outputs 1 | ||
Length 25mm | ||
Width 25mm | ||
Depth 16mm | ||
Dimensions 25 x 25 x 16mm | ||
Weight 16g | ||
Mounting Type PCB Mount | ||
Minimum Temperature -25°C | ||
Efficiency 63% | ||
Maximum Temperature +80°C | ||
Minimum Operating Frequency 47Hz | ||
Maximum Operating Frequency 63Hz | ||
- COO (Country of Origin):
- CN
1 to 3W Small Compact Size - PCB Mount
Single Output – Primary Side Regulated
Output Range : 3.3VDC - 24VDC
Input Range : 85VAC - 265VAC/47 - 63Hz Or 120VDC - 370VDC
Very Low Standby Power Consumption < 0.15W
Encapsulated Design And Same Footprint As EE20 Transformer:Upgrade Your Application Without Redesign Of PCB
Materials : Plastic And Resin
Single Output – Primary Side Regulated
Output Range : 3.3VDC - 24VDC
Input Range : 85VAC - 265VAC/47 - 63Hz Or 120VDC - 370VDC
Very Low Standby Power Consumption < 0.15W
Encapsulated Design And Same Footprint As EE20 Transformer:Upgrade Your Application Without Redesign Of PCB
Materials : Plastic And Resin
