RS PRO Spring Plunger Microswitch, Wire Lead Terminal, 15A @ 250V ac, SPDT, IP54
- RS Stock No.:
- 249-6828
- Manufacturer:
- RS PRO
80 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Price Each (In a Pack of 5)
MYR25.686
Units | Per Unit | Per Pack* |
|---|---|---|
| 5 - 45 | MYR25.686 | MYR128.43 |
| 50 - 495 | MYR24.92 | MYR124.60 |
| 500 + | MYR20.51 | MYR102.55 |
*price indicative
- RS Stock No.:
- 249-6828
- Manufacturer:
- RS PRO
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- IN
Product Details
RS PRO 1NO/1NC Miniature Roller Plunger Micro Switch (15 A @ 125/250V)
The RS PRO miniature Micro Switch featuring a Beryllium Copper trident Spring Plunger actuator operated via a Zinc alloy lever with a free running Nylon roller contained in a Phenolic thermo-setting plastic case for a robust and reliable mechanism.
The RS PRO Micro Switch is designed with a snap action 1NO/NC contact arrangement and M3 Brass terminal screws (located in the 4.0mm wiring channel) protected and insulated by the removable insulated base plate.
The micro switch features Silver contacts avoiding the risk of contact oxidisation and maintaining secure and reliable conductivity throughout its mechanical life creating a hard wearing and consistent Roller Plunger switch ideal for a range of environments and applications.
Features and Benefits
- Spring Plunger actuator
- Contact Configuration SPDT
- Contact Arrangement 1NO/1NC
- Phenolic thermosetting plastic case
- Snap action
- Silver contacts
- M3 Brass screw terminals
- Side mounted
- Total weight of 123.3g
Approvals and Standards: CE, CSA, UKCA, IEC 1508-1
Why RS PRO?
RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards; they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
Specifications
Attribute | Value |
|---|---|
| Actuator Type | Spring Plunger |
| Terminal Type | Wire Lead |
| Contact Current Rating | 15A @ 250V ac |
| Contact Configuration | SPDT |
| IP Rating | IP54 |
| Operating Force | 300g |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | +70°C |
| Contact Material | Sliver |
| Case Material | Phenolic |
| Mechanical Life | 1000000Operations |
| Voltage Rating | 125/250V |
| Release Force | 100g |
