HV56022-V/KNX Microchip Instrumentation Amplifier, 110 mV Offset 124 Hz, 20-Pin 40 mA VQFN

This image is representative of the product range

View all Instrumentation Amplifiers
Bulk discount available
View bulk pricing options

Subtotal (1 pack of 5 units)*

MYR48.59

Add to Basket
Select or type quantity
Stock information currently inaccessible - Please check back later

Units
Per Unit
Per Pack*
5 - 5MYR9.718MYR48.59
10 - 20MYR9.522MYR47.61
25 - 45MYR9.332MYR46.66
50 - 85MYR9.146MYR45.73
90 +MYR8.964MYR44.82

*price indicative

Packaging Options:
RS Stock No.:
251-6966
Mfr. Part No.:
HV56022-V/KNX
Manufacturer:
Microchip
Find similar products by selecting one or more attributes.
Select all

Brand

Microchip

Product Type

Instrumentation Amplifier

Package Type

VQFN

Mount Type

Surface

Pin Count

20

Maximum Supply Voltage

5.5V

Minimum Supply Voltage

3.3V

Vos - Input Offset Voltage

110 mV

Minimum Operating Temperature

0°C

Maximum Operating Temperature

125°C

Standards/Approvals

RoHS

Length

4mm

GBP - Gain Bandwidth Product

124Hz

Height

900μm

Series

HV56022

Supply Current

40mA

Automotive Standard

No

The Microchip HV56022 family is a dual channel high voltage amplifier for driving piezo actuators for haptic applications, such as kemet film actuators, and other solutions. The opamps are designed to drive haptic (piezo) actuators at 225V with 40 mA minimum source/sink current.

Dual 250V Operational Amplifiers

Driving Thin-Film Piezoelectric Actuator for Haptics
