HARTING, 50 m Cat5e Ethernet Cable, Yellow Polyurethane Sheath Screened, Shielded
- RS Stock No.:
- 913-1829
- Mfr. Part No.:
- 09456000146
- Manufacturer:
- HARTING
Subtotal (1 reel of 50 metres)*
MYR3,916.48
FREE delivery for orders over RM 500.00
Last RS stock
- Final 1 unit(s), ready to ship from another location
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | MYR3,916.48 | MYR78.33 |
*price indicative
- RS Stock No.:
- 913-1829
- Mfr. Part No.:
- 09456000146
- Manufacturer:
- HARTING
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Product Type | Ethernet Cable | |
| Cable Length | 50m | |
| LAN Category | Cat5e | |
| Shield Type | Shielded | |
| Screened/Unscreened | Screened | |
| Conductor Type | Stranded | |
| Jacket Material | Polyurethane | |
| Jacket Colour | Yellow | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 70°C | |
| Core Strands | 19 | |
| Cable CSA | 0.13mm² | |
| Fire Behaviour | Flame Retardant, Halogen Free | |
| Standards/Approvals | EN 50 173-3:2007, EN 50 288-2-2:2004, IEC 61 156-6:2002, ISO/IEC 11 801, ISO/IEC 24 702:2006 | |
| Number of Cores | 8 | |
| Conductor Material | Copper | |
| Outside Diameter | 6.8mm | |
| Select all | ||
|---|---|---|
Brand HARTING | ||
Product Type Ethernet Cable | ||
Cable Length 50m | ||
LAN Category Cat5e | ||
Shield Type Shielded | ||
Screened/Unscreened Screened | ||
Conductor Type Stranded | ||
Jacket Material Polyurethane | ||
Jacket Colour Yellow | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 70°C | ||
Core Strands 19 | ||
Cable CSA 0.13mm² | ||
Fire Behaviour Flame Retardant, Halogen Free | ||
Standards/Approvals EN 50 173-3:2007, EN 50 288-2-2:2004, IEC 61 156-6:2002, ISO/IEC 11 801, ISO/IEC 24 702:2006 | ||
Number of Cores 8 | ||
Conductor Material Copper | ||
Outside Diameter 6.8mm | ||
HARTING Industrial Cat5 Cable - PUR
A high speed, flexible data cable, designed for installation in drag-chains, where Cat6a specification transmission performance is required.
· Fully screened design provides good EMC capability
· Double jacketed
· Flame retardant
· Halogen free
· Fully screened by an overall wire braid
Applications
· Cat5 specification
· Drag-chain cables
· Trailing cable
