Belden 1888ELV, 500 m Cat7a Ethernet Cable, S/FTP, Grey Screened Low Smoke Zero Halogen Sheath

RS Stock No.:: 175-6546
Mfr. Part No.:: 1888ELV.00500
Manufacturer:: Belden

Belden 1888ELV, 500 m Cat7a Ethernet Cable, S/FTP, Grey Screened Low Smoke Zero Halogen Sheath

Subtotal (1 reel of 500 metres)*

MYR13,781.04

FREE delivery for orders over RM 500.00

Temporarily out of stock

Shipping from 14 May 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Reel(s)	Per Reel	Per Metre*
1 +	MYR13,781.04	MYR27.562

*price indicative

RS Stock No.:: 175-6546
Mfr. Part No.:: 1888ELV.00500
Manufacturer:: Belden

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Belden
	Product Type	Ethernet Cable
	Series	1888ELV
	Cable Length	500m
	LAN Category	Cat7a
	Shield Type	S/FTP
	Sub Type	Cat7a+ S/FTP
	Screened/Unscreened	Screened
	Conductor Type	Solid
	Jacket Colour	Grey
	Jacket Material	Low Smoke Zero Halogen
	Minimum Operating Temperature	30°C
	Maximum Operating Temperature	60°C
	Standards/Approvals	IEC 60754-1, EN50267-1, EN 50173-1 Ed. 3:2011
	Fire Behaviour	LSZH, FRNC
	Voltage	72 V
	Conductor Material	Bare Copper
	Number of Cores	8
	Outside Diameter	8.1 mm

	Select all
	Brand Belden
	Product Type Ethernet Cable
	Series 1888ELV
	Cable Length 500m
	LAN Category Cat7a
	Shield Type S/FTP
	Sub Type Cat7a+ S/FTP
	Screened/Unscreened Screened
	Conductor Type Solid
	Jacket Colour Grey
	Jacket Material Low Smoke Zero Halogen
	Minimum Operating Temperature 30°C
	Maximum Operating Temperature 60°C
	Standards/Approvals IEC 60754-1, EN50267-1, EN 50173-1 Ed. 3:2011
	Fire Behaviour LSZH, FRNC
	Voltage 72 V
	Conductor Material Bare Copper
	Number of Cores 8
	Outside Diameter 8.1 mm

COO (Country of Origin):: HU

CAT7A (1000MHz), 4-Pair, S/FTP shielded, Premise Horizontal Cable, 22 AWG solid bare copper conductors, Foam Polyolefin insulation, each pair with Beldfoil® shield, overall tinned copper braid shield (50% coverage), LSZH jacket
