TRACOPOWER TMV 2HI DC-DC Converter, ±9V dc/ ±112mA Output, 4.5 → 5.5 V dc Input, 2W, Through Hole, +80°C Max
- RS Stock No.:
- 898-7034
- Mfr. Part No.:
- TMV 2-0509DHI
- Manufacturer:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)**
MYR59.47
71 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over MYR500.00
Real time qty checker
Units | Per Unit |
---|---|
1 - 2 | MYR59.47 |
3 - 4 | MYR58.22 |
5 + | MYR56.44 |
**price indicative
- RS Stock No.:
- 898-7034
- Mfr. Part No.:
- TMV 2-0509DHI
- Manufacturer:
- TRACOPOWER
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TRACOPOWER | |
Output Voltage | ±9V dc | |
Input Voltage Range | 4.5 → 5.5 V dc | |
Power Rating | 2W | |
Input Voltage Nominal | 5 V dc | |
Output Current | ±112mA | |
Mounting Type | Through Hole | |
Isolated | Yes | |
Number of Outputs | 2 | |
Output Voltage Adjustment Range | ±8.55 V dc, ±9.45V dc | |
Package | SIP 7 | |
Isolation Voltage | 5.2kV dc | |
Length | 19.5mm | |
Depth | 10.2mm | |
Width | 7.1mm | |
Series | TMV 2HI | |
Load Regulation | <10% | |
Efficiency | 75% | |
Maximum Temperature | +80°C | |
Minimum Temperature | -40°C | |
Standards Met | A1:2010, A1:2011, A11:2009, A12:2011, Am 1:2009, ANSI/UL No. 60950-1 2nd ed., CAN/CSA-C22.2 No 60950-1-07 2nd ed, CB, cSAus, EN 60950-1:2006, IEC 60950-1:2005 (2nd edition), REACH, ROHS | |
Select all | ||
---|---|---|
Brand TRACOPOWER | ||
Output Voltage ±9V dc | ||
Input Voltage Range 4.5 → 5.5 V dc | ||
Power Rating 2W | ||
Input Voltage Nominal 5 V dc | ||
Output Current ±112mA | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 2 | ||
Output Voltage Adjustment Range ±8.55 V dc, ±9.45V dc | ||
Package SIP 7 | ||
Isolation Voltage 5.2kV dc | ||
Length 19.5mm | ||
Depth 10.2mm | ||
Width 7.1mm | ||
Series TMV 2HI | ||
Load Regulation <10% | ||
Efficiency 75% | ||
Maximum Temperature +80°C | ||
Minimum Temperature -40°C | ||
Standards Met A1:2010, A1:2011, A11:2009, A12:2011, Am 1:2009, ANSI/UL No. 60950-1 2nd ed., CAN/CSA-C22.2 No 60950-1-07 2nd ed, CB, cSAus, EN 60950-1:2006, IEC 60950-1:2005 (2nd edition), REACH, ROHS | ||
