MEAN WELL DC-DC Converter, 48V dc/ 4.2A Output, 19 → 36 V dc Input, 200W, Chassis Mount, +60°C Max Temp -20°C
- RS Stock No.:
- 678-3607
- Distrelec Article No.:
- 169-26-194
- Mfr. Part No.:
- SD-200B-48
- Manufacturer:
- MEAN WELL
Bulk discount available
Subtotal (1 unit)**
MYR527.77
20 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over MYR500.00
Real time qty checker
Units | Per Unit |
|---|---|
| 1 - 4 | MYR527.77 |
| 5 - 9 | MYR517.23 |
| 10 - 24 | MYR506.88 |
| 25 - 124 | MYR496.74 |
| 125 + | MYR486.81 |
**price indicative
- RS Stock No.:
- 678-3607
- Distrelec Article No.:
- 169-26-194
- Mfr. Part No.:
- SD-200B-48
- Manufacturer:
- MEAN WELL
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Output Voltage | 48V dc | |
| Input Voltage Range | 19 → 36 V dc | |
| Power Rating | 200W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 4.2A | |
| Mounting Type | Chassis Mount | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | 43 → 53V | |
| Isolation Voltage | 1.5kV ac | |
| Width | 115mm | |
| Depth | 50mm | |
| Length | 215mm | |
| Load Regulation | ±1% | |
| Efficiency | 86% | |
| Maximum Temperature | +60°C | |
| Standards Met | 3, 4, 5, 6, 8, EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A | |
| Minimum Temperature | -20°C | |
Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Output Voltage 48V dc | ||
Input Voltage Range 19 → 36 V dc | ||
Power Rating 200W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 4.2A | ||
Mounting Type Chassis Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range 43 → 53V | ||
Isolation Voltage 1.5kV ac | ||
Width 115mm | ||
Depth 50mm | ||
Length 215mm | ||
Load Regulation ±1% | ||
Efficiency 86% | ||
Maximum Temperature +60°C | ||
Standards Met 3, 4, 5, 6, 8, EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A | ||
Minimum Temperature -20°C | ||
