TRACOPOWER TEN 40E DC-DC Converter, ±12V dc/ 1.66A Output, 18 → 36 V dc Input, 40W, Through Hole, +85°C Max Temp

RS Stock No.:: 194-4628
Mfr. Part No.:: TEN 40-2422E
Manufacturer:: TRACOPOWER

TRACOPOWER TEN 40E DC-DC Converter, ±12V dc/ 1.66A Output, 18 → 36 V dc Input, 40W, Through Hole, +85°C Max Temp

Bulk discount available

Price Each**

MYR297.75

61 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over MYR700.00

Units	Per Unit
1 - 2	MYR297.75
3 - 4	MYR288.81
5 +	MYR279.87

**price indicative

RS Stock No.:: 194-4628
Mfr. Part No.:: TEN 40-2422E
Manufacturer:: TRACOPOWER

TRACOPOWER TEN 40E Series DC-DC Converter, 91 (Typ.)% Efficiency, 1.131kV DC/1.6kV DC Isolation Voltage - TEN 40-2422E

This isolated DC-DC converter delivers reliable ±12 V DC power for various industrial applications, efficiently handling an input voltage range of 18 to 36 V DC. Its compact size of 2 in x 1 in ensures it integrates well into automation, electronics, and electrical systems while maintaining performance under high temperatures.

Features & Benefits

• High efficiency of up to 91%, minimising heat generation
• Operates effectively in extreme temperatures from -40°C to +85°C
• Dual output capability to accommodate different circuit requirements
• Remote On/Off feature for energy-efficient operation
• Protection against short circuits and overvoltage situations
• Thru-hole mounting for straightforward integration into existing designs

Applications

• Suitable for automation equipment requiring stable power
• Ideal for telecommunications systems that need dual output
• Utilised in medical devices relying on dependable power supplies
• Appropriate for industrial power supply solutions in harsh conditions

What is the maximum load I can connect to this device?

The device supports a maximum power output of 40 W, allowing it to manage load requirements without derating.

Can this converter handle varying input voltages within its range?

Yes, it can effectively manage an input voltage range of 18 to 36 V DC, providing flexibility for different applications.

How do I implement the remote On/Off feature?

The remote control can be activated with a voltage input of 3.0 to 12 VDC, enabling easy integration into your setup.

Is there a need for additional cooling when operating at high temperatures?

No additional cooling is required unless operating temperatures exceed the specified limits, which may require thermal management strategies.

What is the typical response time for transient loads?

The response time for transient loads is approximately 250 μs, allowing quick adaptation to shifting load conditions.

For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.

Attribute	Value
Output Voltage	±12V dc
Input Voltage Range	18 → 36 V dc
Power Rating	40W
Input Voltage Nominal	24 V dc
Output Current	1.66A
Mounting Type	Through Hole
Isolated	Yes
Number of Outputs	2
Output Voltage Adjustment Range	-10 → +20%
Package	2 in x 1 in Case
Isolation Voltage	1.131 kV dc, 1.6kV dc
Depth	10.2mm
Length	50.8mm
Width	25.4mm
Series	TEN 40E
Load Regulation	0.005
Efficiency	91 (Typ.)%
Minimum Temperature	-40°C
Maximum Temperature	+85°C
Standards Met	IEC/EN 62368-1
