Units	Per Unit
1 - 2	MYR15.44
3 - 4	MYR15.11
5 +	MYR14.64

Select all	Attribute	Value
	Brand	TRACOPOWER
	Output Voltage	9V dc
	Input Voltage Range	10.8 → 13.2 V dc
	Power Rating	1W
	Input Voltage Nominal	12 V dc
	Output Current	110mA
	Mounting Type	Through Hole
	Isolated	Yes
	Number of Outputs	1
	Package	SIP
	Isolation Voltage	1.5kV dc
	Length	11.68mm
	Width	6mm
	Depth	9.7mm
	Series	TBA 1
	Railway Approved	No
	Load Regulation	1.5%
	Maximum Temperature	+85°C
	Standards Met	IEC/EN 62368-1
	Medical Approved	No
	Efficiency	79%
	Minimum Temperature	-40°C

	Select all
	Brand TRACOPOWER
	Output Voltage 9V dc
	Input Voltage Range 10.8 → 13.2 V dc
	Power Rating 1W
	Input Voltage Nominal 12 V dc
	Output Current 110mA
	Mounting Type Through Hole
	Isolated Yes
	Number of Outputs 1
	Package SIP
	Isolation Voltage 1.5kV dc
	Length 11.68mm
	Width 6mm
	Depth 9.7mm
	Series TBA 1
	Railway Approved No
	Load Regulation 1.5%
	Maximum Temperature +85°C
	Standards Met IEC/EN 62368-1
	Medical Approved No
	Efficiency 79%
	Minimum Temperature -40°C

TRACOPOWER TBA 1 DC-DC Converter, 9V dc/ 110mA Output, 10.8 → 13.2 V dc Input, 1W, Through Hole, +85°C Max Temp

FREE delivery for orders over MYR500.00

TRACOPOWER TBA 1 Series DC-DC Converter, 9V DC Output Voltage, 1W Power Rating - TBA 1-1219

Features & Benefits

Applications

What is the typical efficiency I can expect from this unit?

Can this device work in high-temperature environments?

Is this component suitable for use in medical applications?

How many outputs does this converter provide?

What type of mounting does this converter support?

For these non-cancellable (NC), and non-returnable (NR) products, Terms and Conditions apply.
