Cosel MGF DC/DC Converter, 12V dc, -12 V dc/ 130 mA, 48V dc Input, 48V dc Input 3.12 W, PCB, 85 °C Max Temp -40 °C Min
- RS Stock No.:
- 171-4844
- Mfr. Part No.:
- MGFW34812
- Manufacturer:
- Cosel
Bulk discount available
Subtotal (1 tube of 10 units)*
MYR781.04
FREE delivery for orders over RM 500.00
Temporarily out of stock
- Shipping from 17 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per Unit* |
|---|---|---|
| 1 - 1 | MYR781.04 | MYR78.104 |
| 2 - 3 | MYR763.86 | MYR76.386 |
| 4 + | MYR747.46 | MYR74.746 |
*price indicative
- RS Stock No.:
- 171-4844
- Mfr. Part No.:
- MGFW34812
- Manufacturer:
- Cosel
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 12, -12V dc | |
| Minimum Input Voltage | 48V dc | |
| Maximum Input Voltage | 48V dc | |
| Output Current 1 | 130mA | |
| Mount Type | PCB | |
| Number of Outputs | 2 | |
| Isolation Voltage | 1kV dc | |
| Package Type | SIP-6 | |
| Maximum Output Power | 3.12W | |
| Length | 17mm | |
| Depth | 12mm | |
| Standards/Approvals | cUL, EN 62368-1, RoHS, UL 60950-1 | |
| Width | 8.5mm | |
| Series | MGF | |
| Weight | 4g | |
| Efficiency | 81% | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Product Type DC/DC Converter | ||
Output Voltage 1 12, -12V dc | ||
Minimum Input Voltage 48V dc | ||
Maximum Input Voltage 48V dc | ||
Output Current 1 130mA | ||
Mount Type PCB | ||
Number of Outputs 2 | ||
Isolation Voltage 1kV dc | ||
Package Type SIP-6 | ||
Maximum Output Power 3.12W | ||
Length 17mm | ||
Depth 12mm | ||
Standards/Approvals cUL, EN 62368-1, RoHS, UL 60950-1 | ||
Width 8.5mm | ||
Series MGF | ||
Weight 4g | ||
Efficiency 81% | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
- COO (Country of Origin):
- JP
Industry Standard
Wide input range DC9-36V/DC18-76V
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
High reliability : not built-in aluminium and tantalum electrolytic capacitor
