Units	Per Unit
1 - 4	MYR56.20
5 - 9	MYR54.53
10 - 24	MYR52.86
25 - 49	MYR51.74
50 +	MYR50.62

Select all	Attribute	Value
	Brand	TDK-Lambda
	Output Voltage	±12V dc
	Input Voltage Range	9 → 18 V dc
	Power Rating	3W
	Input Voltage Nominal	12 V dc
	Output Current	125mA
	Mounting Type	Through Hole
	Isolated	Yes
	Number of Outputs	2
	Output Voltage Adjustment Range	±11.4 → ±15V
	Package	DIP
	Isolation Voltage	500V ac
	Width	16.6mm
	Depth	8.5mm
	Length	22.86mm
	Series	CC-E
	Load Regulation	600mV
	Standards Met	CE, cULus, EN 60950-1, NEMKO, UL/CSA 60950-1
	Minimum Temperature	-40°C
	Maximum Temperature	+85°C
	Efficiency	81%

	Select all
	Brand TDK-Lambda
	Output Voltage ±12V dc
	Input Voltage Range 9 → 18 V dc
	Power Rating 3W
	Input Voltage Nominal 12 V dc
	Output Current 125mA
	Mounting Type Through Hole
	Isolated Yes
	Number of Outputs 2
	Output Voltage Adjustment Range ±11.4 → ±15V
	Package DIP
	Isolation Voltage 500V ac
	Width 16.6mm
	Depth 8.5mm
	Length 22.86mm
	Series CC-E
	Load Regulation 600mV
	Standards Met CE, cULus, EN 60950-1, NEMKO, UL/CSA 60950-1
	Minimum Temperature -40°C
	Maximum Temperature +85°C
	Efficiency 81%

TDK-Lambda CC-E DC-DC Converter, ±12V dc/ 125mA Output, 9 → 18 V dc Input, 3W, Through Hole, +85°C Max Temp

FREE delivery for orders over MYR500.00

CC-E Series, 1 W to 12 W Single/Dual Output

Features and Benefits
