MEAN WELL DC-DC Converter, 12V dc/ 40A Output, 19 → 72 V dc Input, 500W, Rack Mount, +60°C Max Temp -20°C Min

RS Stock No.:: 491-267
Distrelec Article No.:: 169-26-282
Mfr. Part No.:: SD-500L-12
Manufacturer:: MEAN WELL

MEAN WELL DC-DC Converter, 12V dc/ 40A Output, 19 → 72 V dc Input, 500W, Rack Mount, +60°C Max Temp -20°C Min

Bulk discount available

Subtotal (1 unit)**

MYR727.03

8 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over MYR500.00

Real time qty checker

Units	Per Unit
1 - 4	MYR727.03
5 - 9	MYR711.78
10 - 24	MYR690.43
25 - 49	MYR673.45
50 +	MYR658.71

**price indicative

Compare

RS Stock No.:: 491-267
Distrelec Article No.:: 169-26-282
Mfr. Part No.:: SD-500L-12
Manufacturer:: MEAN WELL

SD-500 Series specification sheet
Declaration Of Conformity

Attribute	Value
Output Voltage	12V dc
Input Voltage Range	19 → 72 V dc
Power Rating	500W
Input Voltage Nominal	19 → 72 V dc
Output Current	40A
Mounting Type	Rack Mount
Isolated	Yes
Number of Outputs	1
Output Voltage Adjustment Range	11 → 15V
Isolation Voltage	2kV ac
Length	215mm
Width	115mm
Depth	50mm
Load Regulation	±0.5%
Maximum Temperature	+60°C
Efficiency	86%
Standards Met	3, 4, 5, 6, 8, EN 55022 (CISPR22) Class B, EN 61000-4-2, ENV 50204, Heavy Industry Level Criteria A
Minimum Temperature	-20°C

MEAN WELL DC-DC Converter, 12V dc/ 40A Output, 19 → 72 V dc Input, 500W, Rack Mount, +60°C Max Temp -20°C Min

FREE delivery for orders over MYR500.00

SD- 500 Series Single Output Enclosed Regulated Isolated DC-DC Converter
