    Molex Mini KK Series Female Crimp Terminal, 28AWG Min, 22AWG Max

    Molex Mini KK Series Female Crimp Terminal, 28AWG Min, 22AWG Max
    1 / 2
    View all Crimp Contacts
    Bulk discount available

    Subtotal (1 pack of 50 units)**

    MYR28.80

    Add to Basket
    Select or type quantity
    3200 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*

    * Delivery dates may change based on your chosen quantity and delivery address.

    Real time qty checker
    Units
    Per Unit
    Per Pack**
    50 - 450MYR0.576MYR28.80
    500 - 1450MYR0.564MYR28.20
    1500 - 3700MYR0.547MYR27.35
    3750 - 7450MYR0.534MYR26.70
    7500 +MYR0.522MYR26.10

    **price indicative

    RS Stock No.:
    821-5452
    Mfr. Part No.:
    08-70-0049
    Manufacturer:
    Molex
    Find similar products by selecting one or more attributes.
    Select all

    Brand

    Molex

    Gender

    Female

    For Use With

    KK 254 and KK Connector Housings

    Series

    Mini KK

    Minimum Wire Size mm²

    0.08mm²

    Maximum Wire Size mm²

    0.35mm²

    Termination Method

    Crimp

    Contact Plating

    Tin

    Minimum Wire Size AWG

    28AWG

    Contact Material

    Phosphor Bronze

    Maximum Wire Size AWG

    22AWG

    Series Number

    5159

    Minimum Operating Temperature

    -40°C

    Maximum Current

    3A

    Maximum Operating Temperature

    +105°C
