Rittal TopTherm Blue e Series Enclosure Cooling Unit, 460W, 315 m³/h 230V ac 620 mm 285mm 298 mm
- RS Stock No.:
- 223-9990
- Mfr. Part No.:
- 3303508
- Manufacturer:
- Rittal
Bulk discount available
Subtotal (1 unit)*
MYR15,830.97
FREE delivery for orders over RM 500.00
Stocked by manufacturer
- Ready to ship from 08 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 - 4 | MYR15,830.97 |
| 5 - 9 | MYR15,197.74 |
| 10 + | MYR14,564.51 |
*price indicative
- RS Stock No.:
- 223-9990
- Mfr. Part No.:
- 3303508
- Manufacturer:
- Rittal
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Rittal | |
| Product Type | Enclosure Cooling Unit | |
| Maximum Cooling Power | 460W | |
| Air Flow | 315m³/h | |
| Mount Type | Wall | |
| Input Power | 350W | |
| Connection Type | Plug-In Terminal Strip | |
| IP Rating | IP34, IP56 | |
| Maximum Supply Voltage | 230V ac | |
| Certification | FTTA, UL, EAC, CCC, cUL | |
| Material | Sheet Steel | |
| Min Temperature Setting | -40°C | |
| Depth | 298mm | |
| Height | 620mm | |
| Standards/Approvals | UL+C-UL-FTTA, C-UL, CCC, EAC | |
| Series | TopTherm Blue e | |
| Weight | 25kg | |
| Width | 285mm | |
| Refrigerant Type | R134A | |
| Cooling Capacity | 2.5kW | |
| Frequency | 60Hz | |
| Nominal Current | 2.6A | |
| Select all | ||
|---|---|---|
Brand Rittal | ||
Product Type Enclosure Cooling Unit | ||
Maximum Cooling Power 460W | ||
Air Flow 315m³/h | ||
Mount Type Wall | ||
Input Power 350W | ||
Connection Type Plug-In Terminal Strip | ||
IP Rating IP34, IP56 | ||
Maximum Supply Voltage 230V ac | ||
Certification FTTA, UL, EAC, CCC, cUL | ||
Material Sheet Steel | ||
Min Temperature Setting -40°C | ||
Depth 298mm | ||
Height 620mm | ||
Standards/Approvals UL+C-UL-FTTA, C-UL, CCC, EAC | ||
Series TopTherm Blue e | ||
Weight 25kg | ||
Width 285mm | ||
Refrigerant Type R134A | ||
Cooling Capacity 2.5kW | ||
Frequency 60Hz | ||
Nominal Current 2.6A | ||
- COO (Country of Origin):
- IT
The Rittal SK series is the wall mounted cooling unit with e comfort controller integrated as standard, RiNano coating on the condenser and electrical condensate evaporation. The total cooling output is 0.46 kW and the material used is the sheet steel.
Suitable for outdoor siting
Blue e technology
May be linked to the IoT interface via the Blue e IoT adaptor
