Lovato Electric CN Contactor, 230V ac Coil, 4-Pole, 30 A, 7.5 kW 230V ac, 4 NO, 4kV ac

View all Contactors

Subtotal (1 unit)*

MYR958.43

Add to Basket
Select or type quantity
Stock information currently inaccessible - Please check back later
Units
Per Unit
1 +MYR958.43

*price indicative

RS Stock No.:
122-0174
Mfr. Part No.:
CN6310220
Manufacturer:
Lovato Electric
Find similar products by selecting one or more attributes.
Select all

Brand

Lovato Electric

Coil Voltage

230V ac

Product Type

Contactor

Number of Poles

4

Contact Voltage

4kV ac

Contact Current

30A

Series

CN

Power Rating

7.5kW

Mount Type

DIN Rail

Function

Motor Control

Normal State Configuration

4 NO

Auxiliary Contact Configuration

1 NO

Number of Auxiliary Contacts

1

Terminal Type

Screw

Control Circuit Voltage Uc

230V ac

Contactor Application

Motor Control

Operational Current Ie

63A

Minimum Operating Temperature

-5°C

Maximum Operating Temperature

55°C

Standards/Approvals

EAC, IEC, RoHS, UL, CCC, CSA, cULus

Length

53.5mm

Width

65mm

Depth

85mm

Pole and Throw Configuration

4PST

COO (Country of Origin):
IT

CN63 Series


Professional range of Lovato modular contactors from the CN63 series. The contactors incorporate a DC powered magnetic core system insuring silent operation and noise damping during the control phase. Overvoltage protection circuit and voltage peak limitation of the magnetic core. The contactors come with an operation flag indicator. Application where the contactors are used include lighting systems, electric home heating, heat pumps and ventilation.

35 mm DIN Rail mount

NO + NC Contact configuration

Operation flag indicator

Lovato Orange Contactors, Control Relays and Accessories
