Alpha Wire Alpha Essentials Data & Bus Cable Series, 30m, RG6/U Coaxial, Unterminated75 Ω

RS Stock No.:: 749-1614
Mfr. Part No.:: 6458 BK005
Manufacturer:: Alpha Wire

Alpha Wire Alpha Essentials Data & Bus Cable Series, 30m, RG6/U Coaxial, Unterminated75 Ω

Subtotal (1 reel of 30 metres)**

MYR537.97

4 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over MYR700.00

Reel(s)	Per Reel	Per Metre**
1 +	MYR537.97	MYR17.932

**price indicative

RS Stock No.:: 749-1614
Mfr. Part No.:: 6458 BK005
Manufacturer:: Alpha Wire

ControlNet Coaxial Cable Product Specifications
Cable Selection Guide

Attribute	Value
Terminated/Unterminated	Unterminated
Coaxial Type	RG6/U
Outer Diameter	7.57mm
Characteristic Impedance	75 Ω
Attenuation	1.1 dB/100m @ 1MHz, 1.2 dB/100m @ 2MHz, 1.5 dB/100m @ 5MHz, 1.9 dB/100m @ 10MHz, 11.4 dB/100m @ 300MHz, 13.3 dB/100m @ 400MHz, 2.8 dB/100m @ 20MHz, 4.5 dB/100m @ 50MHz, 6.5 dB/100m @ 100MHz, 9.3 dB/100m @ 200MHz
Length	30m
Sheath Colour	Black
Conductor Strand Type	Solid
Conductor Material	Bare Copper
Capacitance	53.1pF/m
Series	Alpha Essentials
Sheath Material	Polyvinyl Chloride PVC
Operating Temperature Range	-30 → +75 °C
Maximum Operating Temperature	+75°C
Standards Met	CE, CSA, UL
Minimum Operating Temperature	-30°C
Velocity ratio	82%
Insulation Material	Foam PE
Shielding	Foil/Braid Shield

Alpha Wire Alpha Essentials Data & Bus Cable Series, 30m, RG6/U Coaxial, Unterminated75 Ω

FREE delivery for orders over MYR700.00

ControlNet RG6/U Cable

Features and Benefit

Standards and Approvals

ControlNet Cable

6458 BK005
