Development Tool Accessories

Description:
The TTL-234X-5V and TTL-234X-3V3 cables are both terminated by a 6 way, 0.1”, Single-In-Line (SIL) connector. The difference between the two cables is that the TTL-234X-5V operates at +5V levels (signals and power supply) and the TTL-234X-3V3 operates at +3.3V ...

Description:
The TTL-234X-3V3-2mm cable is terminated by an 8 way, 2mm pitch, Single-In-Line (SIL) keyed connector. The TTL-234X-3V3-2mm operates at +3.3V levels (signals only, VCC=+5V). These cables are primarily intended for interfacing the FTDI VDRIVE2 and VMUSIC2 modules. Note that when ...

Description:
The JTAG-HS3 programming cable allows high-speed programming/debugging of Xilinx FPGA and SoC devices from a host PC. • Separate Vref drives JTAG signal voltages• Vref can be any voltage between +1.8V and +5V• USB 2.0 HS port drives JTAG bus ...

Description:
The JTAG-HS2 programming cable allows high-speed programming of Xilinx FPGA devices from a host PC. • Compatible with all Xilinx tools• Compatible with IEEE 1149.7-2009 Class T0 - Class T4 (includes 2-Wire JTAG)• On-board ADP123AUJZ 300mA voltage regulator• Separate Vref ...
