Cosel Embedded Switch Mode Power Supply, ADA600F-48 48V, 12.5 A, 600 W, Input 85V ac to 370V
- RS Stock No.:
- 328-153
- Mfr. Part No.:
- ADA600F-48
- Manufacturer:
- Cosel
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 328-153
- Mfr. Part No.:
- ADA600F-48
- Manufacturer:
- Cosel
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Product Type | Embedded Switch Mode Power Supply | |
| Maximum Output Voltage | 48V | |
| Number of Outputs | 1 | |
| Mount Type | Chassis | |
| Power | 600W | |
| Minimum Operating Temperature | -10°C | |
| SMPS Output Current | 12.5 A | |
| Maximum Operating Temperature | 71°C | |
| Depth | 127mm | |
| Standards/Approvals | CE, RoHS, UL | |
| Width | 65 mm | |
| Weight | 1.5kg | |
| Efficiency | 89% | |
| Maximum Input Voltage | 370V | |
| Series | ADA600F | |
| Hazardous Area Certification | No | |
| Minimum Input Voltage | 85V ac | |
| Output Current | 12.5A | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Product Type Embedded Switch Mode Power Supply | ||
Maximum Output Voltage 48V | ||
Number of Outputs 1 | ||
Mount Type Chassis | ||
Power 600W | ||
Minimum Operating Temperature -10°C | ||
SMPS Output Current 12.5 A | ||
Maximum Operating Temperature 71°C | ||
Depth 127mm | ||
Standards/Approvals CE, RoHS, UL | ||
Width 65 mm | ||
Weight 1.5kg | ||
Efficiency 89% | ||
Maximum Input Voltage 370V | ||
Series ADA600F | ||
Hazardous Area Certification No | ||
Minimum Input Voltage 85V ac | ||
Output Current 12.5A | ||
- COO (Country of Origin):
- JP
Cosel 600-1000 ADA Series Switch Mode Power Supplies
Cosel ADA switch mode power supplies (SMPS) have been designed for the commercial market. Available with a rated output of 600 W to 1000 W, the ADA series offers a durable, high-quality solution featuring high power and peak power. With a universal rated input voltage of AC85 - 264 V 1Φ, these SMPS are incredibly versatile. The series features output voltage options of 24 V, 30 V, 36 V or 48 V.
Features and Benefits:
Green LED operating indicator;Current monitor;Harmonic attenuator that complies with IEC61000-3-2;Optional power up with fan;Parallel master/slave and N+1 redundant operation;Power Factor Correction;Optional alarms;Optional remote ON/OFF;Optional 35mm DIN Rail;Forced air or convection cooling method;-10 °C to +71 °C, 20% RH to 90% RH (Non-condensing);Terminal block terminations
Product Applications:
Suitable applications include lab analysing equipment, motors, routers, lasers, printers and LED signs.
Switch Mode - Cosel Closed Frame
Note
The rated load current depends on whether convection cooling or forced air is used. Please refer to the derating curve.
Standards
UL60950-1, C-UL(CSA60950-1), EN60950-1, EN60065, EN50178 Complies with DEN-AN and IEC60950-1 (At only AC input)
Complies with FCC-B, CISPR22-B, EN55022-B, VCCI-B for conducted noise
Complies with IEC61000-3-2
Complies with FCC-B, CISPR22-B, EN55022-B, VCCI-B for conducted noise
Complies with IEC61000-3-2
