C&K’s SDB series cost effective low profile DIP switches are used by designers as address switches for industrial controls, for logic switching in computers and peripherals and for function controlling in numerous additional applications. The low-profile design of the switches save space and come available in thru-hole and surface mount models, with tape and reel packaging available.

Low profile design saves space
Thru-hole and surface mount models
Tape and reel packaging available
Top tape seal options
Address switch for industrial controls
Logic switching for computers and peripherals
Function controlling for numerous applications

Select all	Attribute	Value
	Brand	C & K
	Number of Positions	10
	Mounting Type	Surface Mount
	Contact Material	Phosphor Bronze
	Contact Configuration	10P10T
	Package Style	DIP
	Actuator Type	Flush Slide
	Contact Current Rating	100 mA
	Maximum Operating Temperature	+85°C
	Minimum Operating Temperature	-40°C
	Operating Temperature Range	-40 → +85°C
	Voltage Rating	50V dc
	Dielectric Strength	300 (Minimum)V dc

	Select all
	Brand C & K
	Number of Positions 10
	Mounting Type Surface Mount
	Contact Material Phosphor Bronze
	Contact Configuration 10P10T
	Package Style DIP
	Actuator Type Flush Slide
	Contact Current Rating 100 mA
	Maximum Operating Temperature +85°C
	Minimum Operating Temperature -40°C
	Operating Temperature Range -40 → +85°C
	Voltage Rating 50V dc
	Dielectric Strength 300 (Minimum)V dc

C & K 10 Way Surface Mount DIP Switch 10P10T, Flush Slide Actuator
