TRACOPOWER TEN 40WIE DC-DC Converter, ±12V dc/ 1.66A Output, 9 → 36 V dc Input, 40W, Through Hole, +85°C Max
- RS Stock No.:
- 194-4662
- Distrelec Article No.:
- 301-62-103
- Mfr. Part No.:
- TEN 40-2422WIE
- Manufacturer:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)**
MYR347.95
5 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over MYR500.00
Real time qty checker
Units | Per Unit |
|---|---|
| 1 - 2 | MYR347.95 |
| 3 - 4 | MYR337.52 |
| 5 + | MYR327.08 |
**price indicative
- RS Stock No.:
- 194-4662
- Distrelec Article No.:
- 301-62-103
- Mfr. Part No.:
- TEN 40-2422WIE
- Manufacturer:
- TRACOPOWER
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | ±12V dc | |
| Input Voltage Range | 9 → 36 V dc | |
| Power Rating | 40W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 1.66A | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 2 | |
| Output Voltage Adjustment Range | ±10% | |
| Package | 2 in x 1 in Case | |
| Isolation Voltage | 1.131 kV dc, 1.6kV dc | |
| Width | 25.4mm | |
| Length | 50.8mm | |
| Depth | 10.2mm | |
| Series | TEN 40WIE | |
| Load Regulation | 0.005 | |
| Efficiency | 91 (Typ.)% | |
| Maximum Temperature | +85°C | |
| Minimum Temperature | -40°C | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage ±12V dc | ||
Input Voltage Range 9 → 36 V dc | ||
Power Rating 40W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 1.66A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 2 | ||
Output Voltage Adjustment Range ±10% | ||
Package 2 in x 1 in Case | ||
Isolation Voltage 1.131 kV dc, 1.6kV dc | ||
Width 25.4mm | ||
Length 50.8mm | ||
Depth 10.2mm | ||
Series TEN 40WIE | ||
Load Regulation 0.005 | ||
Efficiency 91 (Typ.)% | ||
Maximum Temperature +85°C | ||
Minimum Temperature -40°C | ||
