Sanyo Denki San Ace B52 9BC Series Blower Centrifugal Fan, 24V dc, 4.4 cfm, DC Operation 53.6 mm x 52mm x 15 mm
- RS Stock No.:
- 191-9266
- Distrelec Article No.:
- 301-54-323
- Mfr. Part No.:
- 109BC24GC7-1
- Manufacturer:
- Sanyo Denki
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
MYR84.19
FREE delivery for orders over RM 150.00
In Stock
- 20 unit(s) ready to ship from another location
- Plus 26 unit(s) shipping from 05 November 2026
- Plus 49 unit(s) shipping from 19 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 - 4 | MYR84.19 |
| 5 - 9 | MYR82.42 |
| 10 - 24 | MYR79.90 |
| 25 - 49 | MYR77.96 |
| 50 + | MYR76.27 |
*price indicative
- RS Stock No.:
- 191-9266
- Distrelec Article No.:
- 301-54-323
- Mfr. Part No.:
- 109BC24GC7-1
- Manufacturer:
- Sanyo Denki
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Sanyo Denki | |
| Supply Voltage | 24V dc | |
| Product Type | Centrifugal Fan | |
| Blower Type | Blower | |
| AC or DC Operation | DC | |
| Air Flow | 4.4cfm | |
| Series | San Ace B52 9BC | |
| Width | 52mm | |
| Terminal Type | Wire | |
| Fan Speed | 6200rpm | |
| Sensor Output Type | Pulse | |
| Noise Level | 43dBA | |
| Bearing Type | Ball | |
| Height | 53.6mm | |
| Standards/Approvals | UL, RoHS | |
| Depth | 15mm | |
| Maximum Current | 70mA | |
| Static Pressure | 215Pa | |
| Mounting Hole Diameter | 4.5 mm | |
| Select all | ||
|---|---|---|
Brand Sanyo Denki | ||
Supply Voltage 24V dc | ||
Product Type Centrifugal Fan | ||
Blower Type Blower | ||
AC or DC Operation DC | ||
Air Flow 4.4cfm | ||
Series San Ace B52 9BC | ||
Width 52mm | ||
Terminal Type Wire | ||
Fan Speed 6200rpm | ||
Sensor Output Type Pulse | ||
Noise Level 43dBA | ||
Bearing Type Ball | ||
Height 53.6mm | ||
Standards/Approvals UL, RoHS | ||
Depth 15mm | ||
Maximum Current 70mA | ||
Static Pressure 215Pa | ||
Mounting Hole Diameter 4.5 mm | ||
- COO (Country of Origin):
- PH
Sanyo Denki Blower, 15mm Width, 43dB Noise Level - San Ace B52 9BC Series - 109BC24GC7-1
Blow away ventilation issues with this centrifugal blower from Sanyo Denki. It provides an efficient method of cooling thanks to the forward-curved blades, which are angled in the same direction as the fan wheel's rotation. The pulse sensor output keeps tabs on the fan's performance, so you'll know when it's ready for maintenance. This blower packs a practical punch, as its low volume level of 43dB ensures there's minimal background noise.
Features & Benefits
• High static pressure of 215Pa for efficient air pressure production
• Horizontal or vertical mounting for flexible assembly
• Plastic frame and impellers for resistance to impact and corrosion
• Ball bearing mechanism generates low friction to prevent overheating
Applications
• HVAC systems
• Pollution control
• Air filtration products
What are the dimensions of this blower?
This blower has compact dimensions of 51 (L) x 15 (W) x 52.6mm (H) to take up minimal space.
What's the voltage rating of this product?
This blower has a voltage rating of 24V DC, so it's just the thing for use in low-power applications.
