Bootlace Ferrules

Crimp bootlace ferrules are metal tubes crimped (compressed for the purpose of joining) over a stranded wire to allow for a reliable connection with screw or spring clamps. Most
bootlace ferrules have a colour-coded insulation collar that protects the connection from contacts.

How do bootlace ferrules work?

With crimp bootlace ferrules, you crimp the component's metal tube rather than the insulation, whereas with a standard terminal you do the opposite.

Once you have stripped your wire or cable, push it into the ferrule through the plastic collar so that the conductor insulation covers the entire collar and the stripped part is in the metal tube. You then use a crimping tool to crimp the metal tube to hold the wire or cable in place for a stable connection.

What are bootlace ferrules used for?

Crimp bootlace ferrules are used to provide the high degree of contact reliability required by a wide range of applications. They are available in a variety of designs to suit different wire or cable sizes.

Where are they used?

  • Control units
  • Switching cabinets
  • Function units
  • Equipment with poke-in clamp or row clamp connectors

...
Read more Read less

Filters

Viewing 1 - 20 of 573 products
Results per page
Description Price Maximum Wire Size mm² Pin Diameter Insulation Material Number of Entries Colour Pin Length Insulation Maximum Wire Size AWG Overall Length Series Minimum Wire Size mm² Minimum Wire Size AWG
RS Stock No. 458-774
BrandRS PRO
MYR0.278
Each (In a Pack of 100)
units
1.5mm² 2mm Nylon 1 Red 8mm Insulated 16AWG 14.5mm - - -
RS Stock No. 458-689
BrandRS PRO
MYR0.104
Each (In a Pack of 100)
units
0.5mm² 1.3mm Nylon 1 White 8mm Insulated 22AWG 14mm - - -
RS Stock No. 157-1200
BrandRS PRO
MYR0.252
Each (In a Pack of 100)
units
0.25mm² 1.1mm Nylon 1 Blue 8mm Insulated 26AWG 12.4mm - - -
RS Stock No. 458-702
BrandRS PRO
MYR0.104
Each (In a Pack of 100)
units
1mm² 1.7mm Nylon 1 Red 8mm Insulated 18AWG 14.5mm - - -
RS Stock No. 458-718
BrandRS PRO
MYR0.192
Each (In a Pack of 100)
units
1.5mm² 2mm Nylon 1 Black 8mm Insulated 16AWG 14.5mm - - -
RS Stock No. 458-780
BrandRS PRO
MYR0.125
Each (In a Pack of 100)
units
2.5mm² 2.6mm Nylon 1 Blue 8mm Insulated 14AWG 15mm - - -
RS Stock No. 458-724
BrandRS PRO
MYR0.125
Each (In a Pack of 100)
units
2.5mm² 2.6mm Nylon 1 Grey 8mm Insulated 14AWG 15mm - - -
RS Stock No. 458-695
BrandRS PRO
MYR0.188
Each (In a Pack of 100)
units
0.75mm² 1.5mm Nylon 1 Blue 8mm Insulated 20AWG 14.5mm - - -
RS Stock No. 311-7971
BrandRS PRO
MYR0.569
Each (In a Pack of 100)
units
2 x 0.5mm² 1.5mm Nylon 2 White 8mm Insulated 2 x 22AWG 14.5mm - - -
RS Stock No. 157-1250
BrandRS PRO
MYR0.285
Each (In a Pack of 100)
units
4mm² 3.2mm Nylon 1 Grey 12mm Insulated 12AWG 20mm - - -
RS Stock No. 458-752
BrandRS PRO
MYR0.242
Each (In a Pack of 100)
units
0.75mm² 1.5mm Nylon 1 White 8mm Insulated 20AWG 14.5mm - - -
RS Stock No. 157-1216
BrandRS PRO
MYR0.202
Each (In a Pack of 100)
units
0.25mm² 1.1mm Nylon 1 Purple 8mm Insulated 26AWG 12.4mm - - -
RS Stock No. 513-2607
BrandRS PRO
MYR142.34
1 Bag of 500
Bag(s)
1mm² 1.7mm Nylon 1 Red 8mm Insulated 18AWG 14mm - - -
RS Stock No. 513-2613
BrandRS PRO
MYR41.96
1 Bag of 500
Bag(s)
1.5mm² 2mm Nylon 1 Black 8mm Insulated 16AWG 14mm - - -
RS Stock No. 458-768
BrandRS PRO
MYR0.361
Each (In a Pack of 100)
units
1mm² 1.7mm Nylon 1 Yellow 8mm Insulated 18AWG 14.5mm - - -
RS Stock No. 157-1266
BrandRS PRO
MYR0.331
Each (In a Pack of 100)
units
6mm² 3.9mm Nylon 1 Black 12mm Insulated 10AWG 20mm - - -
RS Stock No. 157-1222
BrandRS PRO
MYR0.239
Each (In a Pack of 100)
units
0.34mm² 1.1mm Nylon 1 Turquoise 8mm Insulated 24AWG 12.4mm - - -
RS Stock No. 211-4319
BrandRS PRO
MYR0.237
Each (In a Pack of 100)
units
4mm² 3.2mm - 1 - 12mm Uninsulated 12AWG 12mm - - -
RS Stock No. 513-2590
BrandRS PRO
MYR60.14
1 Bag of 500
Bag(s)
0.75mm² 1.5mm Nylon 1 Grey 8mm Insulated 20AWG 14mm - - -
RS Stock No. 311-8003
BrandRS PRO
MYR0.784
Each (In a Pack of 100)
units
2 x 6mm² 4.9mm Nylon 2 Yellow 14mm Insulated 2 x 10AWG 26.1mm - - -
