Molex, PicoBlade Female Crimp Connector Housing, 1.25mm Pitch, 4 Way, 1 Row
- RS Stock No.:
- 188-8793
- Mfr. Part No.:
- 51021-0400
- Manufacturer:
- Molex
2000 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Added
Price Each (In a Bag of 2000)
MYR1.121
| Units | Per Unit | Per Bag* |
| 2000 - 2000 | MYR1.121 | MYR2,242.00 |
| 4000 - 6000 | MYR1.099 | MYR2,198.00 |
| 8000 + | MYR1.077 | MYR2,154.00 |
| *price indicative | ||
- RS Stock No.:
- 188-8793
- Mfr. Part No.:
- 51021-0400
- Manufacturer:
- Molex
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
Molex PicoBlade Female Crimp Connector Housing, 4 Way, 1.25mm Pitch - 51021 Series - 51021-0400
This female crimp connector housing from Molex holds your connectors tightly in place on a printed circuit board (PCB). Its polyester resin material is strong and impact-resistant, so you can safely use it in demanding applications. The housing offers space for up to four circuits, while its highly compact dimensions of 6.75 (length) x 3.95 (width) x 3.2mm (depth) means it won't take up much space on your PCB. The slight flexibility of the housing material makes it simple to install without damaging your connection.
• Friction lock keeps PCB connector firmly in place even in the event of heavy vibrations
• Wide operating temperature of -40°C to +105°C for use in demanding environments
• Single-row housing design is easily adaptable to different PCB configurations
• Wide operating temperature of -40°C to +105°C for use in demanding environments
• Single-row housing design is easily adaptable to different PCB configurations
Applications
• Automotive industry
• Security systems
• Data and communications networking
• Medical industry
• Security systems
• Data and communications networking
• Medical industry
What are the advantages of a crimped connector housing?
This crimp connector housing creates an insulated seal with a connector for a dependable, heat-resistant connection. It also protects the connection from moisture and dust, helping it withstand the demands of harsh industrial environments.
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 4 |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Gender | Female |
| Mounting Type | Cable Mount |
| Series | PicoBlade |
| For Use With | 50058 Crimp Terminals, 50079 Crimp Terminals |
| Body Orientation | Straight |
| Length | 6.75mm |
| Width | 3.95mm |
| Housing Material | Polyester |
