Otto Single Pole Single Throw (SPST) Toggle Switch, Momentary, IP68S, Panel Mount

  • RS Stock No. 883-7550
  • Mfr. Part No. T7-111C5
  • Manufacturer Otto
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): US
Product Details

16A Sealed

These rugged, high performance sealed switches are designed for use under severe conditions, typically found in marine, industrial control and appliance applications.
Designed to meet IP68, front panel sealing is accomplished using an O-Ring under the toggle actuator, together with a secondary visible bush seal.

Features and benefits

Precision machined bushing and toggle handle
Sealed to IP68S
Withstands excessive shock and vibration
Positive detent, non-teasable contact transfer
Temperature Range -30°C to +85°C
UL recognised & CSA certified

//media.rs-online.com/t_line/L0294347-01.gif
Specifications
Attribute Value
Contact Configuration SPST
Switch Operation Momentary
Contact Current Rating 16 A
Mounting Type Panel Mount
Terminal Type Tab
IP Rating IP68S
Actuator Length 0.66in
Actuator Material Stainless Steel
Voltage Rating 28 V dc, 115 V ac
Minimum Operating Temperature -30°C
Maximum Operating Temperature +85°C
Mechanical Life 100000Cycles
Standards Met CSA, Reach, RoHS, UL, WEEE
Contact Material Silver
Operating Temperature Range -30 +85°C
28 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 120.22
units
Per unit
1 - 9
MYR120.22
10 - 19
MYR116.61
20 - 49
MYR113.12
50 - 99
MYR109.73
100 +
MYR96.38
