IP67 Blue Side Cap Tactile Switch, Single Pole Single Throw (SPST) 50 mA 6.5 (Dia.)mm PCB

  • RS Stock No. 912-0428
  • Mfr. Part No. 3FTH900
  • Manufacturer MEC
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): DK
Product Details

Multimec® 3F Switches

SPNO momentary action
Sealed to IP67

Specifications
Attribute Value
Contact Configuration Single Pole Single Throw (SPST)
Terminal Type Pc Pin
Switch Operation Momentary
Actuator Length 6.5 (Dia.)mm
Actuator Colour Blue
Actuator Type Side Cap
Length 12.5mm
Width 10.4mm
Dimensions 12.5 x 10.4mm
Illuminated Yes
Mounting Type PCB
Contact Current Rating 50 mA
IP Rating IP67
Operating Force 3.5 N
Maximum Operating Temperature +160°C
Minimum Operating Temperature -40°C
Mechanical Life 10000000Operations
Operating Temperature Range -40 → +160°C
Voltage Rating 24V dc
600 In Global stock for delivery within 4 - 6 working days
Price Each (In a Tube of 50)
MYR 28.804
units
Per unit
Per Tube*
50 - 50
MYR28.804
MYR1,440.20
100 - 200
MYR28.264
MYR1,413.20
250 - 450
MYR26.98
MYR1,349.00
500 - 950
MYR25.053
MYR1,252.65
1000 +
MYR24.259
MYR1,212.95
*price indicative
