Black Button Tactile Switch, Single Pole Single Throw (SPST) 50 mA @ 24 V dc 0.7mm

Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

TE Connectivity FSM Series Tactile Switches

The professional range of tactile switches from TE Connectivity. FSM series switches are suitable for use with mobile devices.

Features and benefits:

SPNO tactile switches available in THT, SMD & right angle mountings
SMD types suitable for immersion

Applications:

• Keyboards
• Keypads
• Telephones
• Radios
• General consumer electronics
• Closing the circuit on a PCV

Tactile

Specifications
Attribute Value
Contact Configuration Single Pole Single Throw (SPST)
Terminal Type Through Hole
Switch Operation Momentary
Actuator Length 0.7mm
Actuator Colour Black
Actuator Type Button
Contact Current Rating 50 mA @ 24 V dc
Operating Force 1.6 N
Maximum Operating Temperature +85°C
Minimum Operating Temperature -35°C
Contact Material Silver Over Nickel Plated Copper Alloy (Stationary); Silver Plated Copper Alloy (Movable)
Operating Temperature Range -35 → +85°C
26250 In Global stock for delivery within 4 - 6 working days
Price Each (In a Bag of 750)
MYR 0.405
units
Per unit
Per Bag*
750 +
MYR0.405
MYR303.75
*price indicative
