Units	Per Unit	Per Pack**
5 - 15	MYR8.112	MYR40.56
20 - 35	MYR7.704	MYR38.52
40 +	MYR7.32	MYR36.60

Select all	Attribute	Value
	Brand	TE Connectivity
	Contact Configuration	SPST
	Terminal Type	PC Pin
	Switch Operation	Momentary
	Actuator Colour	White
	Actuator Type	Rectangular
	Length	6.1mm
	Width	6.1mm
	Dimensions	6.1 x 6.1mm
	Illuminated	Yes
	Mounting Type	Through Hole
	Contact Current Rating	50 mA
	Height	7.8mm
	Operating Force	2.54 N
	Voltage Rating	12V dc
	Operating Temperature Range	-25 °C → +70°C
	Maximum Operating Temperature	+70°C
	Contact Material	Brass
	Minimum Operating Temperature	-25°C

	Select all
	Brand TE Connectivity
	Contact Configuration SPST
	Terminal Type PC Pin
	Switch Operation Momentary
	Actuator Colour White
	Actuator Type Rectangular
	Length 6.1mm
	Width 6.1mm
	Dimensions 6.1 x 6.1mm
	Illuminated Yes
	Mounting Type Through Hole
	Contact Current Rating 50 mA
	Height 7.8mm
	Operating Force 2.54 N
	Voltage Rating 12V dc
	Operating Temperature Range -25 °C → +70°C
	Maximum Operating Temperature +70°C
	Contact Material Brass
	Minimum Operating Temperature -25°C

TE Connectivity White Rectangular Tactile Switch, SPST 50 mA Through Hole

FREE delivery for orders over MYR500.00

TE Alcoswitch Illuminated Tactile Switch Series

Features and Benefits

Applications:
