Carlo Gavazzi RA 24 Series Solid State Relay, 25 A Load, Panel Mount, 265 V ac Load, 32 V dc Control

RS Stock No.:: 856-8377
Mfr. Part No.:: RA2425-D06
Manufacturer:: Carlo Gavazzi

Carlo Gavazzi RA 24 Series Solid State Relay, 25 A Load, Panel Mount, 265 V ac Load, 32 V dc Control

43 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ

Added

Price Each

MYR237.72

Units	Per Unit
1 +	MYR237.72

RS Stock No.:: 856-8377
Mfr. Part No.:: RA2425-D06
Manufacturer:: Carlo Gavazzi

Technical data sheets

Datasheet

Legislation and Compliance

COO (Country of Origin):: MT

Product Details

Carlo Gavazzi RA2 & RA4 Series Zero Switching

Carlo Gavazzi RA2 series of zero switching solid state relays provide the user with a compact solution without compromising on performance or reliability

2 pole AC solid state relay with zero-switching functionality
Suitable for resistive & inductive AC loads
Direct copper bonding (DCB) technology
LED status indication

Zero Voltage Relays

Note

Temperature can affect current rating; please consult the data sheet for potential derating.

Specifications

Attribute	Value
Maximum Load Current	25 A
Mounting Type	Panel Mount
Maximum Load Voltage	265 V ac
Minimum Load Voltage	180 V ac
Maximum Control Voltage	32 V dc
Minimum Control Voltage	3 V dc
Switching Type	Zero
Control Voltage Range	3 → 32 V dc
Minimum Load Current	2 A
Number of Poles	1
Terminal Type	Screw
Output Device	Varistor
Relay Type	Solid State Relay
Maximum Turn On Time	1 s
Series	RA 24
Load Voltage Range	180 → 265V ac
Dimensions	44.5 x 57.8 x 24.5mm
Capacitance	8pF
Maximum Operating Temperature	+70°C
Depth	57.8mm
Minimum Operating Temperature	-20°C
Operating Temperature Range	-20 → +70°C
Off State Leakage Current	1 mA
Length	44.5mm
Special Features	AC Solid State Relay, Zero Switching, Direct Copper Bonding Technology
Height	29mm
