Finder PCB Mount Signal Relay, 24V dc Coil, 2A Switching Current, DPDT
- RS Stock No.:
- 182-9937
- Mfr. Part No.:
- 30.22.9.024.0010
- Manufacturer:
- Finder
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 182-9937
- Mfr. Part No.:
- 30.22.9.024.0010
- Manufacturer:
- Finder
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Coil Voltage | 24V dc | |
| Contact Configuration | DPDT | |
| Mounting Type | PCB Mount | |
| Maximum Switching Current AC | 5 A | |
| Maximum Switching Current DC | 5 A | |
| Maximum Switching Voltage AC | 125/250V | |
| Maximum Switching Power DC | 60 W | |
| Series | Axicom P2 | |
| Length | 14.5mm | |
| Latching | No | |
| Depth | 7.2mm | |
| Height | 9.8mm | |
| Terminal Type | Through Hole | |
| Switching Current | 2A | |
| Number of Poles | 2 | |
| Maximum Switching Power AC | 62.5VA | |
| Life | 100 x 10^3 cycles | |
| Contact Material | Gold Plated | |
| Isolation Coil To Contact | 1.5kV | |
| Coil Power | 200mW | |
| Minimum Operating Temperature | -40°C | |
| Coil Resistance | 4114Ω | |
| Maximum Operating Temperature | +85°C | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Coil Voltage 24V dc | ||
Contact Configuration DPDT | ||
Mounting Type PCB Mount | ||
Maximum Switching Current AC 5 A | ||
Maximum Switching Current DC 5 A | ||
Maximum Switching Voltage AC 125/250V | ||
Maximum Switching Power DC 60 W | ||
Series Axicom P2 | ||
Length 14.5mm | ||
Latching No | ||
Depth 7.2mm | ||
Height 9.8mm | ||
Terminal Type Through Hole | ||
Switching Current 2A | ||
Number of Poles 2 | ||
Maximum Switching Power AC 62.5VA | ||
Life 100 x 10^3 cycles | ||
Contact Material Gold Plated | ||
Isolation Coil To Contact 1.5kV | ||
Coil Power 200mW | ||
Minimum Operating Temperature -40°C | ||
Coil Resistance 4114Ω | ||
Maximum Operating Temperature +85°C | ||
- COO (Country of Origin):
- IT
2 Pole changeover contacts
Low level switching capability
Subminiature
Sensitive DC coil: 200 mW
Wash tight: RT III
Applications
Alarm systems
Automation control
Car accessories
Circuit boards for household equipment
Coil winders
Control systems
Copiers
Door and gate openers
Low level switching capability
Subminiature
Sensitive DC coil: 200 mW
Wash tight: RT III
Applications
Alarm systems
Automation control
Car accessories
Circuit boards for household equipment
Coil winders
Control systems
Copiers
Door and gate openers
