Select all	Attribute	Value
	Brand	Panasonic
	Coil Voltage	5V dc
	Contact Configuration	DPDT
	Mounting Type	PCB Mount
	Maximum Switching Current AC	2 A
	Maximum Switching Current DC	2 A
	Maximum Switching Voltage AC	125V ac
	Maximum Switching Voltage DC	220V dc
	Maximum Switching Power DC	60 W
	Length	14mm
	Latching	Yes
	Depth	9mm
	Height	5mm
	Dimensions	14 x 5 x 9mm
	Terminal Type	Through Hole
	Switching Current	2A
	Maximum Operating Temperature	+70°C
	Minimum Operating Temperature	-40°C
	Coil Resistance	250 <ohm/>
	Operating Temperature Range	-40 → +70°C
	Maximum Switching Power AC	62.5VA
	Life	100000000 (Mechanical) cycles
	Coil Power	100mW
	Isolation Coil To Contact	1kV rms
	Contact Material	Gold Plated

	Select all
	Brand Panasonic
	Coil Voltage 5V dc
	Contact Configuration DPDT
	Mounting Type PCB Mount
	Maximum Switching Current AC 2 A
	Maximum Switching Current DC 2 A
	Maximum Switching Voltage AC 125V ac
	Maximum Switching Voltage DC 220V dc
	Maximum Switching Power DC 60 W
	Length 14mm
	Latching Yes
	Depth 9mm
	Height 5mm
	Dimensions 14 x 5 x 9mm
	Terminal Type Through Hole
	Switching Current 2A
	Maximum Operating Temperature +70°C
	Minimum Operating Temperature -40°C
	Coil Resistance 250 <ohm/>
	Operating Temperature Range -40 → +70°C
	Maximum Switching Power AC 62.5VA
	Life 100000000 (Mechanical) cycles
	Coil Power 100mW
	Isolation Coil To Contact 1kV rms
	Contact Material Gold Plated

Panasonic PCB Mount Latching Signal Relay, 5V dc Coil, 2A Switching Current, DPDT

FREE delivery for orders over MYR500.00

TQ Series, Latching

Approvals
