C & K, 2 Position SPDT Rotary Switch, 2.5 A @ 125 V ac, 350 mA @ 125 V dc, Solder Lug

  • RS Stock No. 155-8817
  • Mfr. Part No. A11442MNZB
  • Manufacturer C & K
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

Multi-pole and multi-position
Positive detent
Shorting & non-shorting contacts
Panel and PCB mounting
RoHS Compliant
Automotive
Major and small appliance
Industrial equipment

Specifications
Attribute Value
Contact Configuration SPDT
Contact Current Rating 2.5 A @ 125 V ac, 350 mA @ 125 V dc
Number of Switch Positions 2
Number of Contacts 2
Voltage Rating 125V ac/dc
Diameter 26.19mm
Dimensions 26.19 (Dia.) x 58.94mm
Mounting Type Panel Mount
Mounting Hole Size 10.21 mm
Terminal Type Solder Lug
Standards Met CULus Recognised, UL 94 V-0
Contact Type Non-Shorting
Minimum Operating Temperature -30°C
Case Material Glass Filled Nylon 6/6
Contact Material Brass (Stationary, Coin Silver (Movable), Terminal)
Angle of Throw 90°
Maximum Operating Temperature +85°C
Actuator Colour Black
Height 58.94mm
50 In Global stock for delivery within 4 - 6 working days
Price Each (In a Tray of 50)
MYR 39.829
units
Per unit
Per Tray*
50 - 100
MYR39.829
MYR1,991.45
150 +
MYR37.838
MYR1,891.90
*price indicative
