Baumer Relative for White Oil Pressure Sensor, 1bar Max Pressure Reading , 10 → 35 V dc, 1.5 in Tri-Clamp, IP67,

  • RS Stock No. 921-3110
  • Mfr. Part No. PFMH-54.BC2R.A1153.51202.2000
  • Manufacturer Baumer
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): DK
Product Details

CombiPress PFMH Temperature Transmitter

Professional range of Baumer temperature transmitters from the CombiTemp PFMH series. The transmitters have a flush diaphragm and built-in graphical display. The temperature transmitters are ideal for food and beverage, pharmaceutical and water treatment.

Flush diaphragm
Built in graphic display

Temperature Transmitters

4 to 20mA loop powered output and reverse polarity protection, configurable without the need for a PC or software

Specifications
Attribute Value
Pressure Reading Type Relative
Minimum Pressure Reading -1bar
Maximum Pressure Reading 1bar
Accuracy ±0.25 %
Output Type Analogue
Media Measured White Oil
Process Connection 1.5 in Tri-Clamp
Analogue Output 4 → 20 mA
Electrical Connection M12 Connector
Response Time ≤0.3 s
Maximum Current 20 mA
Supply Voltage 10 → 35 V dc
Housing Material Stainless Steel
IP Rating IP67, IP69K
Maximum Operating Temperature +85°C
Mounting Type Flush Mount
Minimum Operating Temperature -40°C
1 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 6,379.95
units
Per unit
1 +
MYR6,379.95
