Herga Differential for Fluid Pressure Sensor, 16bar Max Pressure Reading , 250 V ac

  • RS Stock No. 397-1191
  • Mfr. Part No. 6101-0013
  • Manufacturer Herga
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): US
Product Details

Miniature Medium/High Pressure

Rating: 0.69 to17.2 bar (10 to 250 psi)
Die cast housing with integral
1//8 NPT connection, polyurethane diaphragm, silver alloy contacts
External adjustment screw
The switch can be mounted in any orientation to suit a wide variety of applications
Factory fitted spring for operating pressure range 0.69 to 2.76 bar.
Termination type: Faston
3 additional colour coded springs are included for user selection of alternative operating pressure ranges:
Red 2.07 to 8.6 bar
Dark blue 4.13 to 11.71 bar
Yellow 8.6 to 17.2 bar

Approvals

UL recognised

Approvals

UL recognised.

Specifications
Attribute Value
Pressure Reading Type Differential
Minimum Pressure Reading 0.7bar
Maximum Pressure Reading 16bar
Output Type Relay
Media Measured Fluid
Maximum Current 5 A
Supply Voltage 250 V ac
Housing Material Metal
Minimum Operating Temperature -40°C
Maximum Operating Temperature +85°C
66 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 239.75
units
Per unit
1 - 5
MYR239.75
6 - 11
MYR234.80
12 +
MYR233.07
