Select all	Attribute	Value
	Brand	Omron
	Coil Voltage	48V ac
	Contact Configuration	DPDT
	Mounting Type	Plug In
	Switching Current	10A
	Number of Poles	2
	Latching	No
	Terminal Type	Plug In
	Maximum Switching Voltage AC	250V
	Maximum Switching Voltage DC	220V
	Maximum Switching Current AC	10 A
	Maximum Switching Current DC	10 A
	Length	28mm
	Coil Resistance	788 Ω
	Coil Power	900mW
	Isolation Coil To Contact	2kV ac
	Maximum Operating Temperature	+70°C
	Series	MY
	Minimum Operating Temperature	-55°C
	Standards Met	CQC, CSA, IEC, UL
	Contact Material	Silver
	Life	500000 cycles
	Height	36mm
	Depth	36mm
	Number of Coils	Single
	Maximum Switching Power AC	10 VA
	Maximum Switching Power DC	10000 mW
	Width	21.5mm
	Dimensions	28 x 21.5 x 36mm
	Application	General Purpose, Industrial

	Select all
	Brand Omron
	Coil Voltage 48V ac
	Contact Configuration DPDT
	Mounting Type Plug In
	Switching Current 10A
	Number of Poles 2
	Latching No
	Terminal Type Plug In
	Maximum Switching Voltage AC 250V
	Maximum Switching Voltage DC 220V
	Maximum Switching Current AC 10 A
	Maximum Switching Current DC 10 A
	Length 28mm
	Coil Resistance 788 Ω
	Coil Power 900mW
	Isolation Coil To Contact 2kV ac
	Maximum Operating Temperature +70°C
	Series MY
	Minimum Operating Temperature -55°C
	Standards Met CQC, CSA, IEC, UL
	Contact Material Silver
	Life 500000 cycles
	Height 36mm
	Depth 36mm
	Number of Coils Single
	Maximum Switching Power AC 10 VA
	Maximum Switching Power DC 10000 mW
	Width 21.5mm
	Dimensions 28 x 21.5 x 36mm
	Application General Purpose, Industrial

Omron Plug In Power Relay, 48V ac Coil, 10A Switching Current, DPDT

FREE delivery for orders over MYR500.00

OMRON Power Relay, Silver Contacts, 1,000MΩ Insulation Resistance - MY Series - MY2-GS-R AC48

Features & Benefits

Applications

How durable is this power relay?
