Vishay 10kΩ Rotary Potentiometer 5-Turns 1-Gang Panel Mount, 535B1103JC
- RS Stock No.:
- 460-1922
- Mfr. Part No.:
- 535B1103JC
- Manufacturer:
- Vishay
5 In Local stock for delivery in 2-3 working days, delivery time may vary for certain locations or FTZ
10 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Added
Price Each
MYR173.58
| Units | Per Unit |
| 1 - 2 | MYR173.58 |
| 3 - 4 | MYR170.12 |
| 5 + | MYR166.73 |
- RS Stock No.:
- 460-1922
- Mfr. Part No.:
- 535B1103JC
- Manufacturer:
- Vishay
Legislation and Compliance
- COO (Country of Origin):
- MX
Product Details
Vishay 535 Series Wirewound Potentiometers - 5 Turns
• Bushing and servo mount designs available
• Linearity ± 0.25 %, down to 0.05 % on request
• Special resistance tolerances to 1 %
• Rear shaft extensions and support bearing
• Metric shaft available
• Dual gang configuration and concentric shafts
• High torque, center tap, slipping clutch on request
• Special markings and front shaft extensions
• Linearity ± 0.25 %, down to 0.05 % on request
• Special resistance tolerances to 1 %
• Rear shaft extensions and support bearing
• Metric shaft available
• Dual gang configuration and concentric shafts
• High torque, center tap, slipping clutch on request
• Special markings and front shaft extensions
Supplied with
Metal lockwasher and nut.
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Precision - Multi-Turn and Servo
Specifications
Attribute | Value |
|---|---|
| Potentiometer Type | Rotary |
| Maximum Resistance | 10kΩ |
| Number of Gangs | 1 |
| Number of Turns | 5 |
| Power Rating | 1.5W |
| Electrical Taper | Linear |
| Element Material | Wirewound |
| Mounting Type | Panel Mount |
| Termination Style | Solder Lug |
| Shaft Length | 22.2mm |
| Shaft Diameter | 6.35 mm |
| Tolerance | ±5% |
| Series | 535 |
| Actuator Type | Slotted Shaft |
